TFT displays bring life to the project. Why shy with the LCD character display? OLED displays look good and stand out too but small size and limited colors limit the application to basic graphics but are still colorless. No color? No life!

Having the option of TFT display in your next Arduino project can add so many vibrant menu options, can display images, and hence can be a very rich user experience thing.

This is a very basic example of displaying a few texts on the display. We will use the library from Adafruit for the same. The best thing about the Wokwi Embedded systems simulator is that you can run the code straight from the browser. It means, you can easily share the project (as a link) and your friend can run it and lay with the project.

In this article, you will get a working Arduino project which has a simulated TFT display. The display will exactly work in the same way how it would work in the real world and with the real hardware. You can try any TFT project you have!

Let us get started. You will complete the code, connection diagram as well as live working Arduino simulation link so that you can start playing with the code instantly! For more information on the Simulated TFT display,click here.

Our TFT color displays with 2.0" / 2.8" / 3.5" are the further development of the widespread black&white graphic displays: simply connected via SPI interface and therefore suitable for all μC. Alternatively, these small TFTs can also be connected via the classic RGB interface or an 8- or 16-bit data bus.

With its 2" diagonal, the EA TFT020-23AI is indeed a tiny, but the fine resolution of 240x320 pixels conjures up brilliant images at crispy 1000cd/m². The IPS technology provides a gigantic all-round viewing angle with sunlight readability:

The displays have been developed especially for industrial applications and are available for long term. The lifetime is 50,000 hours and the operating temperature range is from -20°C to +70°C.

With the help of a USB cable, the display is connected directly to the PC or a USB power supply. As a stand-alone it is immediately executable at the power supply. Together with a PC and the Simualtortool. "startTFT.exe" you can display your own images or you change the brightness of the backlight. Rotate the screen content in 90° steps.

Interface board EA 9980-TFT for connecting a TFT display to various µC boards. With 50- and 39-pin ZIFF connector. For a fast and uncomplicated connection to your system.

Built-in character sets, graphic functions, adjustable backlight, full touch panel support; these are world-wide unique features. No more working with pixel, but using more than 112 powerful graphic functions. With integrated FLASH for more fonts, pictures and macros. Last but not least there is a cost-free simulator software for the EA eDIP240-7 and a starter kit with USB. Read more about this fine displays on our page eDIP.

The TFT display module supports up to 24-bit pixel format (RGB: 888), allowing a true-color palette of 16,7 million colors, and resolution of 320 x 240 pixels. It features an excellent contrast ratio and uniform brightness. This module is composed of a TFT‐LCD panel, driver IC, FPC, a back light unit.

Honda has posted an online simulator that lets you play with the Africa Twin’s TFT display.   The online simulator offers current or potential future riders the means to introduce themselves to the display’s functions without having to be on or own one of the machines.

Perhaps the online resource is a hidden nod to the complexity that these types of displays bring.  But kudos to Honda.  They are taking the initiative to allow riders to use and understand the system before making an Africa Twin purchase.

The website provides a simulation of the Africa Twin’s TFT display and left and right-hand control switches.  The simulator allows a rider to adjust the multiple settings available on the bike.

Once at the website, you will see a simulated TFT LCD instrument cluster with technical information on the display.  The visitor can customize the readouts with a click of a button on the left-hand control switch.  It’s found on the lower right portion of your monitor.

Unfortunately, there are no detailed instructions on how to use the simulator.  So you’ll have to fiddle a bit with the controls to understand what they do and how to change its settings.  Still, it’s a decent way to get a feel for the display and what it can do for you.

In this Arduino touch screen tutorial we will learn how to use TFT LCD Touch Screen with Arduino. You can watch the following video or read the written tutorial below.

As an example I am using a 3.2” TFT Touch Screen in a combination with a TFT LCD Arduino Mega Shield. We need a shield because the TFT Touch screen works at 3.3V and the Arduino Mega outputs are 5 V. For the first example I have the HC-SR04 ultrasonic sensor, then for the second example an RGB LED with three resistors and a push button for the game example. Also I had to make a custom made pin header like this, by soldering pin headers and bend on of them so I could insert them in between the Arduino Board and the TFT Shield.

Here’s the circuit schematic. We will use the GND pin, the digital pins from 8 to 13, as well as the pin number 14. As the 5V pins are already used by the TFT Screen I will use the pin number 13 as VCC, by setting it right away high in the setup section of code.

I will use the UTFT and URTouch libraries made by Henning Karlsen. Here I would like to say thanks to him for the incredible work he has done. The libraries enable really easy use of the TFT Screens, and they work with many different TFT screens sizes, shields and controllers. You can download these libraries from his website, RinkyDinkElectronics.com and also find a lot of demo examples and detailed documentation of how to use them.

After we include the libraries we need to create UTFT and URTouch objects. The parameters of these objects depends on the model of the TFT Screen and Shield and these details can be also found in the documentation of the libraries.

So now I will explain how we can make the home screen of the program. With the setBackColor() function we need to set the background color of the text, black one in our case. Then we need to set the color to white, set the big font and using the print() function, we will print the string “Arduino TFT Tutorial” at the center of the screen and 10 pixels  down the Y – Axis of the screen. Next we will set the color to red and draw the red line below the text. After that we need to set the color back to white, and print the two other strings, “by HowToMechatronics.com” using the small font and “Select Example” using the big font.

The ILI9341 TFT module contains a display controller with the same name: ILI9341. It’s a color display that uses SPI interface protocol and requires 4 or 5 control pins, it’s low cost and easy to use. The resolution of this TFT display is 240 x 320 which means it has 76800 pixels. This module works with 3.3V only and it doesn’t support 5V (not 5V tolerant).

The ILI9341 TFT display board which is shown in the circuit diagram above has 14 pins, the first 9 pins are for the display and the other 5 pins are for the touch module.

So, the display side pins which numbered from 1 to 9 are (from left to right): VCC (5V), GND (ground), CS (chip select), RST (reset), DC (or D/C: data/command), MOSI (or SDI), SCK (clock), BL (back light LED) and MISO (or SDO).

As mentioned above, the ILI9341 TFT display controller works with 3.3V only (power supply and control lines). The display module is supplied with 5V that comes from the Arduino board. This module has a built-in 3.3V regulator which supplies the display controller with 3.3V from the 5V source.

To connect the Arduino to the display module, I used voltage divider for each line which means there are 5 voltage dividers. Each voltage divider consists of 2.2k and 3.3k resistors, this drops the 5V into 3V which is sufficient.

The first library is a driver for the ILI9341 TFT display which can be installed from Arduino IDE library manager (Sketch —> Include Library —> Manage Libraries …, in the search box write “ili9341” and choose the one from Adafruit).

The ILI9341 TFT display is connected to Arduino hardware SPI module pins (clock and data), the other pins which are: CS (chip select), RST (reset) and DC (data/command) are defined as shown below:

All firmware is the latest available, Marlin 2.03 for the SKR and BIGTREE_TFT35_V3.0.25.1 for the TFT. I"m using the Unified Menu Material theme, and the boards are interconnected with all three cables (correctly orientated on EXP1, EXP2 and RS232/TFT).

This library is a professional graphical stack library to build Graphical User Interfaces (GUIs) with any STM32, any LCD/TFT display and any LCD/TFT controller, taking advantage of STM32 hardware accelerations whenever possible.

The STemWin Library is a comprehensive solution that comes with a rich feature set, such as JPG, GIF and PNG decoding, many widgets (checkboxes, buttons…) and a VNC server enabling the remote display of local displays, as well as professional development tools, such as GUIBuilder to create GUIs with a simple drag and drop.

Our display offer excellent readability for content from all viewing angles. Their high brightness and contrast guarantee that the information is easily readable from long distances. The full colour RGB LED displays are also a first-rate choice for applications where different colours are used for information visualisation.

Our display designed for smooth and reliable operation in the most demanding environments at stations and platforms. They have a wide operating temperature range and the housing is highly protected against wheather and other external impacts.

Our displays are equipped with an industrial PC and intelligent diagnostic unit with versatile features that monitors display performance and operations in real time. The information can be used for preventive maintenance to ensure seamless operation of the displays in field.

Our displays are designed for a long lifetime of over 10 years. Only industrial high quality components are used to ensure long-lasting service-free operation of the device and feature such as low energy consumption allows you to keep operational costs in control.

Hi guys, welcome to today’s tutorial. Today, we will look on how to use the 1.8″ ST7735  colored TFT display with Arduino. The past few tutorials have been focused on how to use the Nokia 5110 LCD display extensively but there will be a time when we will need to use a colored display or something bigger with additional features, that’s where the 1.8″ ST7735 TFT display comes in.

The ST7735 TFT display is a 1.8″ display with a resolution of 128×160 pixels and can display a wide range of colors ( full 18-bit color, 262,144 shades!). The display uses the SPI protocol for communication and has its own pixel-addressable frame buffer which means it can be used with all kinds of microcontroller and you only need 4 i/o pins. To complement the display, it also comes with an SD card slot on which colored bitmaps can be loaded and easily displayed on the screen.

The schematics for this project is fairly easy as the only thing we will be connecting to the Arduino is the display. Connect the display to the Arduino as shown in the schematics below.

Due to variation in display pin out from different manufacturers and for clarity, the pin connection between the Arduino and the TFT display is mapped out below:

We will use two example sketches to demonstrate the use of the ST7735 TFT display. The first example is the lightweight TFT Display text example sketch from the Adafruit TFT examples. It can be accessed by going to examples -> TFT -> Arduino -> TFTDisplaytext. This example displays the analog value of pin A0 on the display. It is one of the easiest examples that can be used to demonstrate the ability of this display.

The second example is the graphics test example from the more capable and heavier Adafruit ST7735 Arduino library. I will explain this particular example as it features the use of the display for diverse purposes including the display of text and “animated” graphics. With the Adafruit ST7735 library installed, this example can be accessed by going to examples -> Adafruit ST7735 library -> graphics test.

Next, we move to the void setup function where we initialize the screen and call different test functions to display certain texts or images.  These functions can be edited to display what you want based on your project needs.

Uploading the code to the Arduino board brings a flash of different shapes and text with different colors on the display. I captured one and its shown in the image below.

That’s it for this tutorial guys, what interesting thing are you going to build with this display? Let’s get the conversation started. Feel free to reach me via the comment section if you have any questions as regards this project.
