cog 160x160 lcd module brands

Dr Pan: Hello, Greg. COG is the abbreviation for chip on glass. It is a technology, which IC is bonded directly onto ITO glass. COG technology is usually used in small size dot matrix monochrome LCD module and TFT LCD module.

NO.1, it can greatly reduce the size of the LCD module because it doesn’t have PCB and it can be as thin as 2.0mm (maybe thinner). The thinner the more expensive.

NO.3, it is cost effective over COB LCD and can totally replace COB LCD in function, especially in graphic LCD modules, because it reduces the number of IC.

NO.4, for some dot matrix LCD modules, it is not possible to apply COB LCD technology because it is too crowded to place so many points on the view area. COG LCD is an economical and feasible solution because the pitch is smaller .

Monochrome Graphic LCDs include TN, STN, FSTN, FFSTN technologies with polarizer in positive mode or negative mode options. COG (Chip on Glass) Constraction. Graphic LCD modules include different options of polarizer in reflective, transmissive or transflective types. LED backlights are available in various colors including yellow/green, white, blue, red, amber and RGB. Available sizes from 1.2’’ to 5.2’’ (128x32~256x128 pixels). Main features:

160x100 Dot Matrix COG, FSTN, Gray background, White Edge lit, Bottom view, Wide temp, Transflective (positive), 3.0V LCD, 3.3V LED, RoHS Compliant. This COG display has a wide temperature range: -20° Celcius to +70° Celcius which equates to (-4° Fahrenheit to +158° Fahrenheit).

FSTN (Film-compensated Super-twisted Nematic) provides a sharper contrast than STN by adding a film. The cost is approximately 5% higher than STN. FSTN works great for indoor and outdoor applications and is mainly used in graphic displays and higher end products. The Transflective polarizer is a mixture of Reflective and Transmissive. It provides the ability to read the LCD with or without the backlight on. It will work for all lighting conditions from dark with backlight to direct sunlight which makes it the most common choice. There is no cost difference between Transflective, Transmissive and Reflective.

Focus LCDs can provide many accessories to go with your display. If you would like to source a connector, cable, test jig or other accessory preassembled to your LCD (or just included in the package), our team will make sure you get the items you need.Get in touch with a team member today to accessorize your display!

Focus Display Solutions (aka: Focus LCDs) offers the original purchaser who has purchased a product from the FocusLCDs.com a limited warranty that the product (including accessories in the product"s package) will be free from defects in material or workmanship.

Guangzhou Tinsharp Industrial Co., Ltd. ， founded in 1995, is one of the major manufacturers of lcd products in China, and it can design and produce all range of liquid crystal products including TN, STN, FSTN LCD displays, standard and customized character type lcd modules or graphical type lcd modules, small and middle size TFT displays.

Vitek is committed to manufacture Graphic LCD Modules, Graphic LCD Display are perfect for applications that require monochrome or multi-colored graphic displays compatible with widely used controllers. We offer a large range of graphic LCD modules that come in different diagonal sizes and resolutions ranging from 122x32 graphic LCD, 128x64 graphic LCD, 144x32 graphic LCD, 160x80 graphic LCD, 192x32 graphic LCD, 192x64 graphic LCD, 160x160 graphic LCD, 240x64 graphic LCD, 240x128 graphic LCD and 320x240 graphic LCD. These Graphic LCD Modules, LCD Graphic Displays are used in applications such as GPS, gaming applications and so on. If you would like to learn more Graphic Modules details, please browse the following categories and feel free to inquire.
