JoaoLopes’s library supports ILI9341, and this one probably is an ILI9341. I checked the SPFD5408 datasheet, and Joao’s library definitely isn’t for SPFD5408. I wonder why he named it so.

Joao Lopes’s library above uses a modified version of the Adafruit TFT library for the hardware layer. The Adafruit TFT library was originally for controlling ILIxxxx series of IC, but this guy modified it for the 8 bit interface of SPFD508.

Now, I’ve seen working code examples for STM32 for the ILIxxxx on Andy’s Workshop blog http://andybrown.me.uk/2012/01/01/stm32 … ft-driver/. So I’m tracking where Joao changed the Adafruit library to try and figure out how to modify an STM32 driver for this TFT.

Okay, I did a git diff on the SPFD5408 library and the Adafruit TFTLCD (for ILI9325 in 8 bit mode) library. Only one thing has been changed, and that is the readID function (it reads a register to identify the chip) which isn’t a big change at all. So I think an STM32 8 bit interface library for ILI9325 should work for the SPFD5408 as well. I’ll look for one or modify andy’s workshop code.

martinayotte wrote:I have an 3.5″ LCD from MCUFriend which looks almost the same as the one above, and I used some parallel 8bits code which use ILI9327 commands.

And also developed a touch screen lib which has some nice features (repeated touch, double touch), check the tftpaint.ino example of the touch library for details.

Theoretically they should give 2500mAh, I will be satisfied if I get 1500mAh out of them, this would mean 12h of 120mA (current consumption of TFT+blue pill).

If you post the defines that you have used in LCD_ID_readreg, I will know your wiring scheme and that it works! I can post a SPECIAL for you. And you can test it. The MapleMini is supported by both Roger’s MapleCore and the Core from ST.

I would get familiar with the basic TFT and GFX methods first. The existing TouchScreen libraries all have issues with Due, Zero, STM32, Teensy, … generally due to pinMode() and digitalWrite() “optimisations”.

I have a tft lcd shield. when I run it use arduino uno, it show me that identifier is ili9325 and works well but when I run it use STM32 blue pill, and this library:

I have run STM32F103 on IteadMaple, Nucleo-F103, and two BluePills. One of the BluePills has its data bus on PA0-PA7. And the Write Cycle is as short as the STM32F103 can possibly make it.

I did it. Pins PA11 PA12 PA15 PB3 PB4 didn’t toggle. I have 2 boards and I test both of them but these pins had problem in both. how can I fix it or change pins in the library????

it do not show until you READ ID of screen. Use LCD_ID_readreg.ino Paste your LCD_ID_readreg.ino example and make photo of your connection to blue pill.

The MCUFRIEND_kbv library is designed for 8-bit Shields. I know that LCD_RD is plugged into Analog #0 pin. Hence my list of #defines in the Readreg sketch.

The MCUFRIEND_kbv library is designed for 8-bit Shields. I know that LCD_RD is plugged into Analog #0 pin. Hence my list of #defines in the Readreg sketch.

It make sense to feed the display with 5V because the regulator on blue pill is not strong enough to deliver the necessary current for the background light of the LCD.

I am trying to interface 2.8inch SPI supported TFT display having ILI9341 driver with STM32F103C8T6 microcontroller. I am using Arduino IDE for programming. There exists different versions of Adafruit_ILI9341 driver libraries. Among them, version "Adafruit_ILI9341_1.52" works well with Arduino Uno. If i try with stm32f103c8t6 by change pin configuration, the display does not work and it shows whitescreen. So suggest me a good ILI9341library for STM32F103C8T6 microcontroller.

3. Some controller chips can operate in more than one mode eg spi/8bit/16bit or external/internal framebuffer. The lcd module you buy will usually be hardwired to operate in a particular mode with no ability to change it. Make sure you get not only the controller you want but also that controller configured in the way you want to use it. Often the choice of the lcd module is what drives all the other decisions.

The above discussion is of course very generic. Knowing more about what you are trying to achieve and what your budget is, or a list of lcd modules you are thinking of, could help us give more specific advice.

Seems interesting UGUI. However for example for the controller ST7586S have any examples of LCD functions to associate with UGUI? If you have made and canst send to me …

Thanks for the extensive library. I see you already used a ST7586S in one of your videos demonstrations. I have a similar display but it draws 2 pixel per byte and not 3 pixel as the datasheet . Can you help me with this ? below is the initialization code i used

I find this library somewhat intriging. Do you have any working Arduino examples, and if it is not asking too much – something for a SSD1322 based display?

AchimAs we"re already talking Microchip, what would be necessary to get a Pic32MZ2048ECH144 and HX8238-A based display to use µGUI?First of all you have to connect the TFT DPI Interface to the PIC. Then initialize the internal DPI Interface of the PIC. After that you only have to write a Pset-function to use uGUI. Hope this helps! By the way: which hardware platform do you use? BR Achim

At first i would like to congratulate you for this great library/project. I tested it in the STM32F429 Discovery and liked a lot. So, I would ask if you are interested in creating an adaptation layer for an event manager based on RTOS services. I beleive that through RTOS semaphores, queues and timers it is possible to better manage the CPU resources. I started myself a GUI event handler, as you can see here:

First, I want to thank you for this library. I"ve used 0.2 version successfully with an OLED with SSD1322 controller on PIC32. Are the window and button functions work on OLED? I haven"t had success with the example code.Hi Andre,

Starting with your example of uGFX 3.0 on Stm32f429-Discovery (embd LCD removed) i have changed only screen dimensions to the ltdc.h in order to make it all work and so on it"s a really good result.

Can I use ugui with STM32F4-Discovery + ssd1963 fsmc module? I have ssd1963 library. I can run the screen but do not know how I could combine seamlessly with ugui. Can you help with this?Hi Mehmet,

I was wondering if I can use this library to get SSD1322 work with xmegaA3AU ? Can you help with some sample code, that would be great! Looking forward to your reply.

We are using Tiny6410 stamp module. It is restricted to using only friendlyarm display. We need to interface resistive touchscreen display of 5 inch & 7 inch of our choice. Please give steps how we can use your library.

i really wonder about your gui. it is very simple to use. i want to draw a image on my lcd. i also done by using your library with given example image. now i want to convert image to header file. can you suggest any software to do that.Hi Arun, I think there is a conversion utility on the ST microelectronics page. I can’t remember the name, but I’m sure there is one. BR Achim

I tried, but I can not force to work my 240×128 display with T6963C controller . Could you please send me the code to this: 240×128 LCD | Driver: T6963C | Interface: 8080

Super nice library. It"s very well coded and easy to use. I"ve began developing on it a couple of days ago and will probably go with your library for the rest of my project.

I"ve set it up on an STM32L100RCT6 with an 128×64 glcd, and everything works like a charm, except the UG_DrawLine() function, which seems to always draw a falling line, no matter how the arguments are arranged
