How is this project going? I think this one was a good decision... Way back last year I experimented with Using a BBS harness for the TSDZ2, now I have a batch of these Motors with the 850C and Bafang Harness ( I see another company does too, actually )...
Maybe there is something I can do, to give us the ability to directly load the firmware into the display, without having to modify it. This would be a great solution for people, as there would be no tampering with the motor or display, simply plug in, and upload new firmware... Of course they may want a metal gear and the temp sensor... which brings me to my last question... Did you have any plans to possibly use other ports for the signal of the temp sensor? If not, perhaps you will reconsider now that you see the 850C model TSDZ2 being available with the BBS harness with throttle etc... it would be nice for people to be able to use the whole system.
I see you are working with another display too as well? FYI I finally got a chance to try your firmware after a leg injury that had me out... it is simply great... it is a bit quieter, can program more power, and the same amount of power if a little more now it seems ~more efficient, and of course, the assist fluctuation seems to "roll on" much more compared to how it used to feel like individual "steps". Small steps, and was still smooth especially compared to cadence sensing, but still, nothing like it is now. GREAT WORK!
Think we have the 800 and there is a 850C that looks like the next level up, I have the Voltbike Yukon 2018 edition. 850c has same password and from same company but not 100% sure if plug and play. Do not want to replace controller or wire connections. Has anyone tried a new display? Do not think any of the DPC stuff will work because for mid-drive. This is the 750 watt geared rear wheel motor G06. Would like to have voltage on display. Maybe a even nicer display than 850c that is plug and play?
Also wondering what happens if you hold all three buttons to factory reset current display? Would I be able to set one time items or would I lock the bike up and need a programmed display straight from VoltBike?
5. Features Suitable for low temperature Max -20℃. High-contrast 3.2inch IPS colourful matrix screen. Ergonomic external button design, easy to operate. Speed display : AVG SPEED, MAX SPEED, SPEED (Real-time). Kilometer / Mile : Can be set according to customers’ habits. ...
7.3 Speed & Mileage mode switch Short press button can change the speed and mileage mode, AVG SPEED- POWER >MAX SPEED->RT SPEED->ODO->RANGE->TIME->TRIP. **If there is no operation for 5 seconds, display will return Speed (Real-Time) display automatically. 7.4 Headlight/backlight On/Off Press and hold button for 1 second can turn on/off the headlight, and the scree will switch to the...
Double press button (press interval less than 0.3 second) can get into setting menus, press button can UP/DOWN buttons to change the parameter setting, press POWER switch to next item. Double press button to exit from menu. POWER * Display will automatically quit menu when there is no operation for 30 seconds. * For safety reasons, display can’t get into MENU when riding.
8.3 Auto off : Press UP/DOWN button to change the auto power off time, from 1 to 9 or OFF, the number represent time (minutes) to shutdown, default value is 5 minutes. 8.4 Scenes : Press UP/DOWN button to change the scenes, Digital / Analog. *Display only support Digital scenes for now, Analog scenes will be supported for future.
You need to input the right password before start with 30 seconds, display will power off automatically if the password was wrong. Basic Setting Ad v ance s etting Wheel Battery Factory setting Information *Press DOWN button to move the red arrow to , press POWER button can show all items of the Basic Setting.
*Speed limit and current limit are restricted by controller and motor. 8.13 Assist levels : This parameter can customize assist levels, options are 3/5/9/UBE, UBE represent factory default settings. Error code :Display the last 10 times error code. 8.14 8.15Factory setting : Press POWER button enter Restore Factory settings item, set YES will restore all parameter to factory settings.
*These information needs to be supported by battery communication. 9. Error Code define 850C can show warning message, icon shows on the screen, and show error code at the bottom of the screen, error code from 04~30, definition see the table below.
0x01 Normal No error 0x03 Brake signal No error 0x04 Throttle on high position Display 04H on speed position 0x05 Throttle error Display 05H on speed position 0x06 Low voltage protection Display 06H on speed position 0x07 High voltage protection Display 07H on speed position 0x08 Line of the Hall on motor...
GREEN PEDEL as a professional ebike display manufacturer and supplier in China, all the ebike display have passed the international industry certification standards, and you can be completely assured of quality. If you do not find your own Intent ebike display in our product list, you can also contact us, we can provide customized services.
