Spice up your Arduino project with a beautiful touchscreen display shield with built in microSD card connection. This TFT display is 2.4" diagonal and colorful (18-bit 262,000 different shades)! 240x320 pixels with individual pixel control. As a bonus, this display has a optional capacitive touch panel and resistive touch panel with controller XPT2046 attached by default.

ER-TFTM024-3 is 240x320 dots 2.4" color tft lcd module display with ILI9341 controller board,superior display quality,super wide viewing angle and easily controlled by MCU such as 8051, PIC, AVR, ARDUINO,ARM and Raspberry PI.It can be used in any embedded systems,industrial device,security and hand-held equipment which requires display in high quality and colorful image.

It supports 8080 8-bit /9-bit/16-bit /18-bit parallel ,3-wire,4-wire serial spi interface.Built-in optional microSD card slot,touch panel controller and 2.4 inch 4-wire resistive touch panel and Capacitive touch panel. It"s optional for font chip, flash chip and microsd card. We offer two types connection,one is pin header and the another is ZIF connector with flat cable mounting on board by default and suggested. Lanscape mode is also available.

Of course, we wouldn"t just leave you with a datasheet and a "good luck!".Here is the link for 2.4"TFT Touch Shield with Libraries, EXxamples.Schematic Diagram for Arduino Due,Mega 2560 and Uno . For 8051 microcontroller user,we prepared the detailed tutorial such as interfacing, demo code and development kit at the bottom of this page.

NHD-2.4-240320CF-CTXI#-FT | 2.4" Standard LCD | 240x320 Pixels | Resistive Touchscreen | Hot-bar Soldering Connection | Screen Printed Icons on Touch Panel | Discontinued EOL Product

This 240x320 resolution LCD TFT is a standard display with 8-bit/16-bit Parallel interface, offering 262K colors, 2.8V power supply, and a 12:00 optimal view. This Liquid Crystal Display has a built-in ILI9341 controller, hot-bar solder connection, has a 4-wire resistive touchscreen and screen printed icons featured on the touch panel. The display is RoHS compliant and has been discontinued. Purchase now while stock is still available!

Those results indicate there is no communication happening with the display chip for some reason. Since the TFT_eSPI library is not used for the test this indicates that the library will not be able to talk to the chip either.

This might not work but try it: The displays are fitted with a regulator (U1 on PCB) which is designed to accept 5V input and output 3.3V to the display. These are normally "Low Drop Out" (LDO) which means that if you connect 3.3V to them they still output about 3.0V and this is sufficient for the display chip. Your board may be fitted with a regulator that has a higher voltage loss, so it is worth trying to power the display from 5V connected to the VCC pin. The other option is to bypass the regulator U1 by soldering a link (or adding a big blob of solder) to short across J1 pads. This then links VCC direct to the TFT chip and thus VCC must only be 3.3V (5V with that link will damage the chip).

2.4 "TFT LCD display with bright backlight (4 LEDs) with a resolution of 240x320 pixels. The display is equipped with a resistive touch panel. The display has a built-in controller with image memory. The display can be controlled in two modes: 8-bit (8 data lines + 5 control lines) parallel and SPI. The display is not equipped with a touch panel controller.
