Thin-Film Transistor Liquid Crystal Displays use thin-film transistors to control the voltage applied to the liquid crystal layer at a sub-pixel level. The structure of TFT LCDs consists of a TFT “sandwich” and a BLU (Backlight Unit). A typical configuration is shown in the schematic diagram below.

Firstly, between the back and front polarizers, TFT LCD cells are made with two glass substrates – one for color filters, the other for a TFT array – and a liquid crystal layer sandwiched in between.

For normally black TFT LCDs, if we follow along a piece of light setting off from its backlight source, it will bea)guided uniformly by LGP;b)reflected and enhanced by BEF and DBEF;c)polarized by the back polarizer;d)polarization changed by twisted LC under the voltage applied by TFT arrays;e)“tinted” red/green/blue by corresponding color filter of the subpixel;f)let through the front polarizer by matched polarization; andg)finally, it will reach the surface and appears in viewer’s eyes.

For normally white panels, processd)will be the opposite – known as the polarization rotation effect, light is twisted in a voltage-off stage and can pass through the front polarizer by default, thus displaying white normally. However, when the voltage applied increases, this polarization rotation effect would be gradually diminished. And the light would not be able to pass through the front polarizer anymore without changing its polarization. In this way, certain pixels will appear in different colors.

Normally black LCDs have higher contrast and wider viewing angles without grayscale inversion phenomenon compared to their normally white relatives. And whether TFT LCDs are normally black or white depends on their LC switching mode:

2Chen, HW., Lee, JH., Lin, BY.et al.Liquid crystal display and organic light-emitting diode display: present status and future perspectives.Light Sci Appl7,17168 (2018).https://doi.org/10.1038/lsa.2017.168

As previously mentioned, TN mode functions with the polarization rotation effect. Under traditional TN/VA display mode, the liquid crystal molecules are vertically arranged, with a relatively narrow visual angle. When an external force is exerted on the screen, the liquid crystal molecular structure will sink in a herringbone pattern to slowly recover – a pattern called vertical alignment. Therefore, an evident “water ripple” usually appears when the display surface is touched and impacts the user experience. In comparison, the VA mode provides higher contrast. And MVA (multi-domain vertical alignment) is an upgraded version of VA with improved viewing angles.

3 Yang DK, Wu ST.Fundamentals of Liquid Crystal Devices. 2nd edition. New York, USA: John Wiley & Sons. 2014.4 BOE ADSDS Ultra Hard screen Technology, Restoring Real and Beautiful Life. 2020 BOE Technology Group Co., Ltd.  Retrieved December 01, 2020, fromhttps://www.boe.com/en/cxkj/boecx/boecxxqy/dynamic/pecbbd751.html

BOE industrial TFT Displays – BOE is the world’s largest global manufacturer of flat panel TFT solutions and one of the world’s most innovative TFT manufacturers.

With sizes ranging from 3.5″ to 55″, BOE panels feature High Definition, High Brightness and Wide Viewing Angles combined with a sleek, functional design.

Peep-proof display and one-button switching of shared status make it possible to satisfy the demands of visual angles of different laptops in different application scenarios. Excellent technical innovations from BOE Displays.

BOE’s own Bright view3 technology for UHD pixel geometry is adopted with a pixel density of retinal class of 326ppi fully illustrating the details.  Another great technological innovation from BOE Displays.

3- and 4-edge narrow bezel design significantly expands the display range for all-around visual enjoyment, integrated bezel-less experience and endlessly expanded visual fields.

A curved surface display for e-sports is featured by the higher response and refresh rate. The curved surface design provides an immersive panoramic view and much better user experience.

BOE opens industry’s first immersive esports experience cabin in Beijing and unveils “Best of Esports” strategy leading the industry towards a new future

BOE Technology Group Co., Ltd., or Jingdongfang (Chinese: 京东方科技集团股份有限公司), is a Chinese electronic components producer founded in April 1993. Its core businesses are interface devices, smart IoT systems and smart medicine and engineering integration.LCD, OLEDs and flexible displays.

In April 1993, Beijing Oriental Electronics Group Co., Ltd was founded by Wang Dongsheng. In 1997, it listed B shares on the Shenzhen Stock Exchange. In 2001, Beijing Oriental Electronics was renamed BOE Technology Group Co., Ltd. BOE acquired SK Hynix"s STN-LCD and OLED businesses for US$22.5 million.flat-panel display businesses for US$380 million.

In 2009, BOE Energy Technology Co., Ltd was founded to enter the photovoltaics industry. In 2010, BOE acquired Suzhou Gaochuang Electronics" Taipei Display Research Center and AIO Manufacturing Plant.

In 2011, BOE established a Japan branch and R&D center in Tokyo. In 2012, BOE established an American branch and R&D center in Santa Clara in Silicon Valley, California. In 2014, BOE established a subsidiary in Frankfurt, Germany. In 2015, BOE acquired OASIS International Hospital.

In 2017, BOE established its Middle East Branch in Dubai and set up a subsidiary based in São Paulo, Brazil. BOE also announced its plan to build a hospital in Chengdu which will be opened in late 2020. BOE announced a long-term agreement with Universal Display Corporation, UDC will supply phosphorescent OLED materials to BOE.LG Display still lead in terms of area shipment.

In 2018, BOE acquired SES-imagotag for €200 million.Kopin Corporation and Olightek for OLED micro-displays manufacturing.Huawei Mate 20 Pro is the first flagship tier smartphone with an AMOLED sourced from BOE (also sourced from LG Display).

In 2019, BOE formed a joint venture with Rohinni for MicroLED and mini LED backlighting manufacturing.Hisense announced its U9E TVs featuring dual LCD panels which Hisense said exceeds OLED TVs in brightness, color gamut and color accuracy. Its panels are produced by BOE.Huawei Mate X scheduled for release in Q4 2019 reportly has a foldable OLED from BOE.Samsung Displays.flat-panel display producer.Huawei to research cameras under OLEDs.LG Display and Tianma as OLED supplier for LG Electronics smartphones in 2020.Apple beginning in 2021 for the iPhone.

In 2021, WIPO’s annual World Intellectual Property Indicators report ranked BOE Technology"s number of patent applications published under the PCT System as 7th in the world, with 1,892 patent applications being published during 2020.

BOE has manufacturing facilities located in Beijing, Hefei, Chengdu, Chongqing, Fuzhou, Mianyang, Wuhan, Kunming, Suzhou, Ordos and Gu"an. BOE has global marketing and R&D centers in 19 countries, such as Japan, South Korea, Singapore, the United States, Germany, the United Kingdom, France, Switzerland, India, Russia, Brazil and Dubai.

Flat-panel displays are thin panels of glass or plastic used for electronically displaying text, images, or video. Liquid crystal displays (LCD), OLED (organic light emitting diode) and microLED displays are not quite the same; since LCD uses a liquid crystal that reacts to an electric current blocking light or allowing it to pass through the panel, whereas OLED/microLED displays consist of electroluminescent organic/inorganic materials that generate light when a current is passed through the material. LCD, OLED and microLED displays are driven using LTPS, IGZO, LTPO, and A-Si TFT transistor technologies as their backplane using ITO to supply current to the transistors and in turn to the liquid crystal or electroluminescent material. Segment and passive OLED and LCD displays do not use a backplane but use indium tin oxide (ITO), a transparent conductive material, to pass current to the electroluminescent material or liquid crystal. In LCDs, there is an even layer of liquid crystal throughout the panel whereas an OLED display has the electroluminescent material only where it is meant to light up. OLEDs, LCDs and microLEDs can be made flexible and transparent, but LCDs require a backlight because they cannot emit light on their own like OLEDs and microLEDs.

Liquid-crystal display (or LCD) is a thin, flat panel used for electronically displaying information such as text, images, and moving pictures. They are usually made of glass but they can also be made out of plastic. Some manufacturers make transparent LCD panels and special sequential color segment LCDs that have higher than usual refresh rates and an RGB backlight. The backlight is synchronized with the display so that the colors will show up as needed. The list of LCD manufacturers:

Organic light emitting diode (or OLED displays) is a thin, flat panel made of glass or plastic used for electronically displaying information such as text, images, and moving pictures. OLED panels can also take the shape of a light panel, where red, green and blue light emitting materials are stacked to create a white light panel. OLED displays can also be made transparent and/or flexible and these transparent panels are available on the market and are widely used in smartphones with under-display optical fingerprint sensors. LCD and OLED displays are available in different shapes, the most prominent of which is a circular display, which is used in smartwatches. The list of OLED display manufacturers:

MicroLED displays is an emerging flat-panel display technology consisting of arrays of microscopic LEDs forming the individual pixel elements. Like OLED, microLED offers infinite contrast ratio, but unlike OLED, microLED is immune to screen burn-in, and consumes less power while having higher light output, as it uses LEDs instead of organic electroluminescent materials, The list of MicroLED display manufacturers:

Sony produces and sells commercial MicroLED displays called CLEDIS (Crystal-LED Integrated Displays, also called Canvas-LED) in small quantities.video walls.

"Samsung Display has halted local Gen-8 LCD lines: sources". THE ELEC, Korea Electronics Industry Media. August 16, 2019. Archived from the original on April 3, 2020. Retrieved December 18, 2019.

"Business Place Information – Global Operation | SAMSUNG DISPLAY". www.samsungdisplay.com. Archived from the original on 2018-03-26. Retrieved 2018-04-01.

"Samsung Display Considering Halting Some LCD Production Lines". 비즈니스코리아 - BusinessKorea. August 16, 2019. Archived from the original on April 5, 2020. Retrieved December 19, 2019.

Herald, The Korea (July 6, 2016). "Samsung Display accelerates transition from LCD to OLED". www.koreaherald.com. Archived from the original on April 1, 2018. Retrieved April 1, 2018.

Byeonghwa, Yeon. "Business Place Information – Global Operation – SAMSUNG DISPLAY". Samsungdisplay.com. Archived from the original on 2018-03-26. Retrieved 2018-04-01.

www.etnews.com (30 June 2017). "Samsung Display to Construct World"s Biggest OLED Plant". Archived from the original on 2019-06-09. Retrieved 2019-06-09.

"China"s BOE to have world"s largest TFT-LCD+AMOLED capacity in 2019". ihsmarkit.com. 2017-03-22. Archived from the original on 2019-08-16. Retrieved 2019-08-17.

LCD manufacturers are mainly located in China, Taiwan, Korea, Japan. Almost all the lcd or TFT manufacturers have built or moved their lcd plants to China on the past decades. Top TFT lcd and oled display manufactuers including BOE, COST, Tianma, IVO from China mainland, and Innolux, AUO from Tianwan, but they have established factories in China mainland as well, and other small-middium sizes lcd manufacturers in China.

China flat display revenue has reached to Sixty billion US Dollars from 2020. there are 35 tft lcd lines (higher than 6 generation lines) in China,China is the best place for seeking the lcd manufacturers.

The first half of 2021, BOE revenue has been reached to twenty billion US dollars, increased more than 90% than thesame time of 2020, the main revenue is from TFT LCD, AMoled. BOE flexible amoled screens" output have been reach to 25KK pcs at the first half of 2021.the new display group Micro LED revenue has been increased to 0.25% of the total revenue as well.

Established in 1993 BOE Technology Group Co. Ltd. is the top1 tft lcd manufacturers in China, headquarter in Beijing, China, BOE has 4 lines of G6 AMOLED production lines that can make flexible OLED, BOE is the authorized screen supplier of Apple, Huawei, Xiaomi, etc,the first G10.5 TFT line is made in BOE.BOE main products is in large sizes of tft lcd panel,the maximum lcd sizes what BOE made is up to 110 inch tft panel, 8k resolution. BOE is the bigger supplier for flexible AM OLED in China.

As the market forecast of 2022, iPhone OLED purchasing quantity would reach 223 million pcs, more 40 million than 2021, the main suppliers of iPhone OLED screen are from Samsung display (61%), LG display (25%), BOE (14%). Samsung also plan to purchase 3.5 million pcs AMOLED screen from BOE for their Galaxy"s screen in 2022.

Technology Co., Ltd), established in 2009. CSOT is the company from TCL, CSOT has eight tft LCD panel plants, four tft lcd modules plants in Shenzhen, Wuhan, Huizhou, Suzhou, Guangzhou and in India. CSOTproviding panels and modules for TV and mobile

three decades.Tianma is the leader of small to medium size displays in technologyin China. Tianma have the tft panel factories in Shenzhen, Shanhai, Chendu, Xiamen city, Tianma"s Shenzhen factory could make the monochrome lcd panel and LCD module, TFT LCD module, TFT touch screen module. Tianma is top 1 manufactures in Automotive display screen and LTPS TFT panel.

Tianma and BOE are the top grade lcd manufacturers in China, because they are big lcd manufacturers, their minimum order quantity would be reached 30k pcs MOQ for small sizes lcd panel. price is also top grade, it might be more expensive 50%~80% than the market price.

Panda electronics is established in 1936, located in Nanjing, Jiangshu, China. Panda has a G6 and G8.6 TFT panel lines (bought from Sharp). The TFT panel technologies are mainly from Sharp, but its technology is not compliance to the other tft panels from other tft manufactures, it lead to the capacity efficiency is lower than other tft panel manufacturers. the latest news in 2022, Panda might be bougt to BOE in this year.

Established in 2005, IVO is located in Kunsan,Jiangshu province, China, IVO have more than 3000 employee, 400 R&D employee, IVO have a G-5 tft panel production line, IVO products are including tft panel for notebook, automotive display, smart phone screen. 60% of IVO tft panel is for notebook application (TOP 6 in the worldwide), 23% for smart phone, 11% for automotive.

Innolux"s 14 plants in Taiwan possess a complete range of 3.5G, 4G, 4.5G, 5G, 6G, 7.5G, and 8.5G-8.6G production line in Taiwan and China mainland, offering a full range of large/medium/small LCD panels and touch-control screens.including 4K2K ultra-high resolution, 3D naked eye, IGZO, LTPS, AMOLED, OLED, and touch-control solutions,full range of TFT LCD panel modules and touch panels, including TV panels, desktop monitors, notebook computer panels, small and medium-sized panels, and medical and automotive panels.

AUO is the tft lcd panel manufacturers in Taiwan,AUO has the lcd factories in Tianma and China mainland,AUOOffer the full range of display products with industry-leading display technology,such as 8K4K resolution TFT lcd panel, wide color gamut, high dynamic range, mini LED backlight, ultra high refresh rate, ultra high brightness and low power consumption. AUO is also actively developing curved, super slim, bezel-less, extreme narrow bezel and free-form technologies that boast aesthetic beauty in terms of design.Micro LED, flexible and foldable AMOLED, and fingerprint sensing technologies were also developed for people to enjoy a new smart living experience.

Hannstar was found in 1998 in Taiwan, Hannstar display hasG5.3 TFT-LCD factory in Tainan and the Nanjing LCM/Touch factories, providing various products and focus on the vertical integration of industrial resources, creating new products for future applications and business models.

driver, backlight etc ,then make it to tft lcd module. so its price is also more expensive than many other lcd module manufacturers in China mainland.

Maclight is a China based display company, located in Shenzhen, China. ISO9001 certified, as a company that more than 10 years working experiences in display, Maclight has the good relationship with top tft panel manufacturers, it guarantee that we could provide a long term stable supply in our products, we commit our products with reliable quality and competitive prices.

Maclight products included monochrome lcd, TFT lcd module and OLED display, touch screen module, Maclight is special in custom lcd display, Sunlight readable tft lcd module, tft lcd with capacitive touch screen. Maclight is the leader of round lcd display. Maclight is also the long term supplier for many lcd companies in USA and Europe.

If you want tobuy lcd moduleorbuy tft screenfrom China with good quality and competitive price, Maclight would be a best choice for your glowing business.

In Taiwan.  It was formed in 2001 by the merger of Acer Display Technology Inc and Unipac Optoelectronics Corporation. It has G3.5 to G8.5 production lines.

In China. The biggest LCD panel manufacturer in the world now.  BOE has G4 (Chengdu), G5 (Beijing), G5.5 (Ordos), G6 (Hefei, Chengdu, Mianyang, Dalian), G8 (Beijing, Hefei, Chongqing), Fuqing, Dalian, Chongqing) and 10.5 (Hefei) production lines.

In Korea and China. It is used to be the 2nd biggest TFT LCD manufacturers. LG also planned to stop the production but delayed the plan after the price increased. LG has G7.5 and G8.5 (Guangzhou) production lines.

In Korea. It used to be the biggest TFT LCD manufacturers before it was dethroned by BOE in 2019. Because of tough competition, Samsung planned to stop the production in 2021 but delayed because the price increase during the pandemic.  Samsung has G7 and G8.5 production lines.

We have some updates from one of the smaller LCD panel manufacturers BOE about their panel development plans. This is BOE as a panel manufacturer, as opposed to any specific monitor/display manufacturer, but it gives an indication of where monitors are likely to go in the future by looking ahead at the panel production plans. Please keep in mind that the production dates are not set in stone and may change, and there is then also a lag of several months before a panel is produced, then used in a display and launched to market. We have updated our panel parts database with all the new information we have as well as best we can.

A lot of the information we have focused on technology improvements in general, and there is less specific information about actual panels and their specs than we have from other manufacturers. We will try and summarise as best we can. BOE are focusing their panel development and investment on several key themes:

One area BOE are developing is the use of a new “OQD” film (we believe this stands for Oxide Quantum Dot). They report that this has a few advantages over traditional QD coatings including being toxic element-free (QD contains Cd/Se apparently), has an improved light efficiency (~90% vs ~70%), no edge degradation and offers the same kind of benefits with wide colour gamut boosting it up to around 170% sRGB.

BOE should already have panel options in production now offering 99% coverage of DCI-P3 and Adobe RGB spaces, as well as 83% BT.2020. There are a couple of 27″ sized panels (panel tech not listed but we expect this to be their ADS technology, IPS-type) with 3840 x 2160 resolution which feature this OQD coating and the above mentioned colour space coverage. One with a 300 cd/m2 brightness in mass production since Sept 2020 and the other which has a slightly boosted brightness of 400 cd/m2 which should have been tested now and hopefully in production also.

BOE also aim to boost this colour gamut a little further in Q1 2021 with coverage up to 90% BT.2020. They are planning a 31.5″ sized panel (tech not listed but again expected to be IPS-type) with 3840 x 2160 resolution and 350 cd/m2 brightness, but no forecast on production dates yet.

BOE are also focusing on developing new panel options with more local dimming zones for improved HDR experiences in the desktop monitor space. There are several Mini LED backlight options being developed. These include

BOE are also focusing on new technologies to enhance the HDR experience further than Mini LED backlights, with even more finite control of the dimming zones and in an effort to compete with the ever-popular OLED technology in this space. One such development is in their BD Cell technology. The following comes from a May 2020 BOE press release talking about BD Cell usage for their 65″ panel which win a SID 2020 Display Industry award, telling us more about what this technology can offer:

As a breakthrough in thin-film transistor (TFT)-LCD technology, BOE’s dual-cell panel—referred to as “BD Cell” for short—offers several important technical advancements that conventional LCD screens don’t. The display uses pixel-level ultra-fine backlight control technology and a brand-new integrated circuit (IC) driving technology to make the million-level contrast ratio rate and 12 bits’ color depth come true, accurately displaying more natural and true-to-life colors. The contrast ratio of a conventional LCD screen is 3,000:1 with 0.2 nits as the lowest brightness. The BD Cell’s screen can raise the contrast ratio up to 150,000:1 and decreasing brightness to 0.003 nit. In terms of combining LED local dimming with BD Cell technology, the contrast ratio can be as high as 2,000,000:1. Moreover, while a conventional LCD screen’s color depth is 8 bit, BD Cell is capable of boosting the color depth as high as 12 bit with an enhanced IC driving algorithm. On the other hand, BD Cell incorporates advantages of an LCD screen’s stableness and technological maturity, with no image sticking.

BOE have two panels in their plans featuring BD Cell technology. The first listed in their plans as BD Cell doesn’t seem to really offer any of the benefits talked about above and is a 23.8″ sized panel with 1920 x 1080 resolution but is listed with an “edge type” backlight system . We are not sure how that fits in with the above description which talks about pixel level backlight control, but this looks to be more like a traditional edge lit local dimming option than any direct lit backlight type and so might not really offer anything significant. There is a >300,000:1 contrast ratio listed, but the screen has only a normal 8-bit colour depth, 350 cd/m2 brightness and standard sRGB gamut (72% NTSC coverage). This is expected to go in to production in Nov 2020.

BOE also have a focus on improving their panel options for gaming screens with their ADS (IPS-type) technology. Already in mass production are a range of panels in sizes of 23.8″, 27″ and 34″ with 144 and 165Hz refresh rates. They are now developing 240Hz versions of the smaller models with the 23.8″ version due to go in to production this month, and the 27″ version which was due to go in to production in Sept. Both are only 1920 x 1080 resolution though.

There’s still a portion of the market who prefer 16:10 aspect ratio screens to common 16:9 offerings. This has commonly been in the 24″ space with 1920 x 1200 resolutions in 16:10 format offering a bit of a vertical boost compared with the common 1920 x 1080 resolutions of the 16:9 format. BOE are still investing in this area with a new 24″ panel planned but this time with a higher 2560 x 1600 resolution. This works out as 125 PPI and the panel also offers a 1000:1 contrast ratio, 350 cd/m2 brightness and 95% DCI-P3 gamut. Production dates are not listed.

The display model YF080B01 is a IPS TFT-LCD(Thin film transistor liquid crystal display)module. This model is Composed of a TFT LCD panel, a driving circuit and a back light, and also has a 8.0 inch diagonally measured active display area with 800 horizontal by 1280 vertical pixel resolution in a stripe arrangement. Display 16M colors by 8 bit R.G.B signal input.

Panox Display provides free connectors for clients who purchase more than five products from us. Our product range includes connectors from Molex, Kyocera, AXE, AXG, JAE, Hiros, and more.

Panox Display provides a customized cover glass/touch panel service. We supply cover glass from Gorilla, AGC, and Panda, which all have excellent optical performance. We also supply driver ICs from Goodix and Focaltech.

If your applications are directly connected to a PC, a cellphone, or Raspberry Pi, and you have enough space to insert a board to input video, Panox Display can provide customized Controller/Driver boards with input connections for VGA, HDMI, DVI, DP, Type-C video input, MIPI, RGB, LVDS, and eDP.
