Low-Voltage Differential Signaling (LVDS) is a technology addressing the needs of today’s high performance data transmission applications. LVDS is a low voltage differential signaling system which is an electrical system and can run at very high speeds over inexpensive, twisted-pair, stranded copper cables. These twisted pairs maintain the 100ohm differential impedance requires by LVDS data signals. LVDS has become a preferred differential standard due to its capability of delivering high data rates while consuming less power than any other interfacing technologies. LVDS uses high-speed analog circuit techniques to provide multi gigabit data transfers on copper interconnects and is a generic interface standard for high-speed data transmission. This is why the LVDS standard is becoming the most popular differential data transmission standard in the industry.

LVDS cables are very popular in electronic communication devices like computers. These cables are of great use in networking as well as in analog video interfacing. The length of data transfer cable assembly can be from 1.00 inch to several meters (6-7) depending on the structure and requirement of the LVDS system.

LVDS is a differential signaling system. It transmits two different voltages which are compared at the receiver end of the transmission. LVDS uses the difference in voltage between the two wires to encode the information. This differential data used in LVDS is less susceptible to common-mode noise than the single-ended schemes. Unlike single-ended methods, differential transmission uses two wires with opposite current/voltage swings, to convey data.

The advantage of the differential approach in LVDS is that noise is usually coupled on the two cables equally and is then rejected by the receivers. The receiver looks at only the difference between the two signals. The differential signals also tend to radiate less noise due to the cancellation of magnetic fields generated as compared to single-ended signals. If in-line noise and EMI are a concern, shielding the overall cable assembly, as well as introducing methods such as ferrite beads and drain wires are several ways this can be addressed. Shielding not only helps to clean up any noise created by the LVDS cables but it also prevents other electronic components from “talking” to the cables distorting image quality and cable function.

LVDS cables are the best choice where low power exists and a large amount of data transfer is required. The main application of LVDS system and cables is in computers. Before LVDS cable assemblies were introduced, the data transfer rate was too slow and cables used to occupy more space.

LVDS cable assemblies are also used in video interfacing devices. They are more commonly used for transporting video data from graphics adapters to computer monitors particularly LCD screens, FPD-Link or OpenLDI standards. These standards of LVDS cable assemblies allow a maximum pixel clock of 112 MHz, which suffices for a display resolution of 1400 x 1050 (SXGA+) at 60 Hz refresh. A dual link can boost the maximum display resolution to 2048 x 1536 (QXGA) at 60 Hz. FPD-Link works with cable lengths up to about 5 m, and LDI extends this to about 10 m.

Quadrangle Products manufactures high quality custom LVDS cable assemblies. Irrespective of the length and purpose, Quadrangle Products can make custom low voltage differential cable assemblies to fit your needs. Each custom cable assembly is built to our customers’ specifications and is 100% quality tested. Our Engineers have designed over 10,000 unique cables and are part of the design process from start to finish, ensuring that each and ever customer receives exactly what they are looking for.

Allow us to help you with your custom cable requirements. We strive to make sure you receive the best solution for your data transfer and other cable needs. We create cables for a wide range of industries including aviation, medical, and defense.

Quadrangle Products Inc. is a Certified ISO 9001:20015 contract manufacturer of wire harnesses and custom cable assemblies with over 30 years of leading industry experience and support. Learn more about other types of cables we offer:

Low-Voltage Differential Signaling (LVDS) cables typically connect a flat panel display to its control board. While some panel and board combinations may work with a stock cable often a custom cable is needed. This is because each flat panel and control board has a unique pinout and connector required to mate with it. Our engineers will work with you to design your custom cable, to determine the connectors needed, the pinout required to properly connect the components, and any other items that may be needed such as EMI protection and shielding, etc.

Low Voltage Differential Signaling (LVDS) cables with twisted pairs. LVDS cables are custom made to interface between your LCD and Control/SBC or Embedded Mother Board. Shielding options available. Lengths vary from 3.00 inches, to as long as 15.00 feet. Fully Customized to meet your exact needs.

With all of the different LCD panel makers, board makers, Inverter and LED Driver makers out there, the endless variety of components and peripherals yield almost endless connector and pin mapping configurations. Our expertise that has made us an industry pioneer is connecting all of these various devices together with quality products. There are thousands of different connectors that appear on these difference devices. Finding a cable house that is tooled for all of these different parts is hard enough. Finding one with the experience and know how to design, scramble pin maps, maintain differential impedance, shield products to mitigate EMI, all while knowing what hidden aspects of the cable design to look for is our business. With well over 10,000 unique designs on file, all with unique bill of materials, and customized to each customers requirements, our experience helps to assist our customers on all levels of the cable design, and subsequent product support thereafter.

In some cases LCD panels will only have (1) connector on them which contains both data and backlight signals. This cable generally yields a "Y" or "V" shaped cable. This is because the SBC (single board computer), Controller or Embedded Motherboard generally has seperate DATA and BACKLIGHT connectors. Is you LCD panel 18bit or 24bit? PWM or Analog dimming? Do you know what screen orientation you need? Is your panel Dual, Single or even Quad Channel LVDS? All of these factors and many more yield the final cable design. This is where we come in. With over 10,000 unique cable designs that we can produce at an time we have the experience to help offer guidance and expertise where needed.

Contact us to learn how we can assist you with your cable needs. At Quadrangle our Engineers are also our Sales team. You will work directly with our Application Engineers who will guide you through the entire cable process including your custom quote. We believe this helps to provide a superior customer experience from concept to turnkey solution.

Confused? Don"t be! More often than not our customers are unfamiliar with the process of acquiring a cable. Our Engineering/Sales support is FREE of charge! We make it as easy as possible to assist you with the design and requirements of your request. Starting with our custom quote, throughout the purchase, and with our continual support over the life of our products, we are sure we will be an asset to you and your company. We consider it our goal to take out most of the guess work providing a simple process resulting in a turnkey product we assure you will be satisfied with.
