The world by nature is three-dimensional (3D). Ideally, a manmade 3D display device should be able to reconstruct the entire information of the light field of a 3D object, independent of the observation method. Holography produces perfect 3D images by reconstituting the amplitude and the phase information of a scene, which can be viewed at a wide angle (Figure 1A). However, the amount of information required to produce a decent hologram is too large to be managed even by modern day electronics, leading to a limited refreshing rate or field of view (FOV) (Tay et al., 2008, Blanche et al., 2010, Butt et al., 2012, Yue et al., 2017). Multiple modulators or holographic projection are used to enlarge the view angle of video rate holography (Li et al., 2016, Zhang et al., 2017, Hahn et al., 2008, Yaraş et al., 2011, Kozacki et al., 2012, Wakunami et al., 2016) by increasing the complexity and the cost of the display systems. The computer-generated holography using metamaterials or metasurfaces can achieve high diffraction efficiency and large FOV (Ozaki et al., 2011, Larouche et al., 2012, Huang et al., 2013, Huang et al., 2015, Ni et al., 2013, Sun et al., 2013, Chen et al., 2013, Li et al., 2015, Almeida et al., 2016, Hu et al., 2019), but the reconstruction of full-color and video rate display are still difficult to accomplish by current methods.

(C) Schematic of holographic sampling displays based on metagratings. When the views are closely arranged, the sampled light field makes a good approximation of the continuous light field.

(E) Schematic of a pixel with three unit cells by combining three LCD units, R/G/B color filters, and the metagratings with varied spatial frequency and orientation. The emergent beams combine to form a colored pixel.

To address the challenge of fulfilling a full-color video rate 3D display, so-called multiview 3D display produces 2D perspective images at a finite number of “views.” 3D display integrated with parallax barrier, lenticular lens array, or microlens arrays all falls into the category (Fattal et al., 2013, Yoon et al., 2011, Xia et al., 2013, Gao et al., 2016, Liu et al., 2017, Li et al., 2017, Martínez-Corral and Javidi, 2018). A prime example of diffraction-based multiview 3D display is made by HP lab a few years ago (Fattal et al., 2013). Periodic diffractive gratings were used to redirect the (semi-)parallel emitting light beams to multiple view angles. As a result, when two perspective images at different direction are captured by eyes, a virtual 3D scene is reconstructed in an observer"s brain by binocular parallax. In other words, the reconstruction of 3D virtual objects in a multiview 3D display depends on whether or not there is an observer and whether we observe it with both eyes or with a single eye.

The employment of periodic micro- or nano-structures as the view modulator leads to two bottlenecks that limit the development of multiview 3D display. Firstly, the emergent light from the abovementioned periodic structures are (semi-)parallel beams. Crosstalk and ghost images happen at the transition region from one view to the other (Figure 1B). Secondly, the failure of reconstructing the phase information at each view leads to vergence-accommodation conflict, the major cause of visual discomfort in multiview 3D display. Vergence-accommodation conflict happens when the depth perception stimulated by binocular parallax is after or behind the display screen, whereas depth recognized by single eye is still at the apparent location of the physical display panel, because the image observed by each eye is still 2D (Inoue and Ohzu, 1997). Such mismatch confuses the brain and more severely, may stimulate nausea and vomit after long-time observation.

In this paper, we propose a holographic sampling 3D display by discretizing a continuous light field function at multiple viewpoints (Figure 1C). A view modulator fully covered with metagratings is utilized to modulate the phase information at each pixel, whereas an LCD (liquid crystal display) panel and a color filter are utilized for the reconstruction of amplitude information at R/B/G wavelength. By reconstructing the wavefront at sampling viewpoints, we greatly suppress the processing data and provide an opportunity for video rate full-color 3D display. When the viewpoints are closely arranged, a good approximation of light field function can be achieved. Compared with the multiview 3D display, the proposed holographic sampling 3D display has the advantages of minimum visual discomfort caused by crosstalk and vergence-accommodation conflict, tailorable viewing window, and simple fabrication process. Our work utilizes the thin and flat view modulator to build a 3D display screen, which is compatible with flat display panel, thus paving the foundation of holographic sampling 3D display for being used in portable electronic devices.
