It is estimated that there are around one billion personal computers around the world, and with every single desktop computer, there is also a monitor attached to it. Every day, hundreds of computer monitors break down, and if you have a LCD monitor that you bought fairly recently and have questioned why it won"t turn on anymore, it"s most likely a power problem that can be fixed to save you hundreds of dollars. This guide will specialize on the computer monitor model LG L196WTQ-BF, but most monitors will follow similar design and can generally be fixed using the same instructions.

That annoying dead pixel on your TFT, OLED, or LCD screen might just be stuck and easy to fix. We"ll show you how to do it. You can still return your monitor if this doesn"t work; nothing we recommend here will void your warranty.

Yes, you should test any new monitor for bad pixels. You can simply run your screen through a palette of basic colors, as well as black and white in full-screen mode using a tool like EIZO Monitor Test.

EIZO Monitor Test is an online tool that lets you find and eventually fix stuck pixels. It packs many options into a single test window, but it"s easy to use once you have an overview.

To test your screen, check all the boxes you want to include in your test. We recommend the default setting of having all boxes checked. If you"re testing multiple monitors, you can open the test on an additional monitor. When you"re ready, click Start test to launch the full-screen test window.

This is a very thorough test not only meant to identify bad pixels but also powerful enough to test the quality of your monitor. Unfortunately, with Flash no longer supported by most browsers, you"ll probably have to use the executable version to make it work.

When all attempts to revive your bad pixel fail, the next best thing you can do is to make peace with it. One ugly pixel won"t break your screen, and eventually, you"ll forget about it. If the defect affects more than a single pixel, however, or just bothers you a lot, you can always replace your monitor.

First, check the warranty. The manufacturer or the marketplace where you purchased the monitor might cover dead pixels. Note that most manufacturers define a maximum number of allowable bad pixels for specific resolutions, and the warranty won"t apply until your monitor crosses that threshold.

Bright or dark sub-pixels can occur during the production of the LCD Monitor panel but does not affect the LCD Monitor functionality. The customer may notice the bright or dark spots if the film of the liquid crystal does not perform as expected while customers uses the LCD monitor. However, this is not considered a defect unless the number of bright and dark subpixels exceeds the maximum allowable threshold (...)

On a monitor with over 12 million pixels (Wide QXGA+, 2560x1600 pixels), for example, LG"s pixel policy says that 12 bright or dark sub-pixels is the maximum you have to tolerate.

Monitor color is not normal, we recommend the first use of the elimination method, as far as possible to eliminate some simple problems. There are many reasons leading to the abnormal display of the display color, such as checking whether the display data line is normal, the display color control panelis not set well, poor contact, or rust of the display wire may lead to such problems.

In addition, there is easier to let people detour the cause of failure – screen dust caused by too much screen white when red! This kind of fault often happens in the monitor that color temperature slants warm (a lot of monitors can set color temperature by oneself), say so, encounter white (and similar color) slants red when the fault you had better be cleaned the first screen later undertake other checks, if the fault disappears, mean you won’t because of this and “unlucky” detour. Of course, too low brightness values on some models can also cause this “fault” phenomenon.

Some people think that this kind of fault is the problem of the line circuit of the monitor — it may be the poor thermal stability of the line tube, the reverse diode, reverse capacitor, and other components or the result of virtual welding. This is completely wrong because none of these components can affect the clarity of the image.

The real failure point of the type 1 fault phenomenon is usually due to the aging of the focusing knob of the FBT. You can try to replace an FBT first. Of course, if the monitor has been in use for more than six years, then we need to take into account the possibility of tube aging. In addition, it may be the tube seat of the picture tube and the large area of the negative copper foil leakage phenomenon caused by the displacer (after analysis like design problems), so sometimes into a maintenance dilemma after the replacement of a genuine tube seat try.

The real fault causes of the first two kinds of faults are usually caused by the virtual welding of some components in the line circuit or the reduction of the +300V filter capacitance at the power supply. The latter possibility is not very high – only in a few models and its more serious loss of volume will cause the human eye to distinguish the flicker. In addition, the circuit of the visual amplifier power supply part of some models is special, and sometimes a component of this part may also cause this fault. Of course, if you set your monitor’s resolution and refresh rate too high or too low, you can set the resolution and refresh rate to the middle value.

There is also a video card or monitor driver there are bugs, so you should first update the driver to try. If the above treatment is not effective, you can focus on checking whether the accelerator voltage and high voltage generated by the FBT are normal, because sometimes these two abnormal voltages can also cause such a phenomenon.

STONE provides a full range of 3.5 inches to 15.1 inches of small and medium-size standard quasi TFT LCD module, LCD display, TFT display module, display industry, industrial LCD screen, under the sunlight visually highlight TFT LCD display, industrial custom TFT screen, TFT LCD screen-wide temperature, industrial TFT LCD screen, touch screen industry. The TFT LCD module is very suitable for industrial control equipment, medical instruments, POS system, electronic consumer products, vehicles, and other products.

To learn how to manually download and install a device driver such as Chipset, Video card (GPU), and Monitor driver (if required, most monitor drivers are delivered automatically through Windows Update) on your Dell computer, see the Dell knowledge base article How to Download and Install Dell Drivers.

It is essential to verify if the problem is inherent with the monitor, video card (GPU) or video settings on your computer. A straightforward way to identify this is to connect the computer to a known-good external monitor or TV and ensure that the display cable (S-video, VGA, DVI, HDMI, DisplayPort, USB-C, or Thunderbolt 3) is firmly connected to the video port on the computer and the monitor.

If the issue persists on the other monitor it may be due to the video card (GPU) or video settings and not the monitor, go to the step Verify display or video issue in Windows Safe Mode. Else go to the next step.

Performance issues may occur if there is any type of damage that is caused to the display cables or the LCD screen. LCD screen may show that symptoms like LCD screen stops working, work intermittently, color mismatch, flickering, display horizontal or vertical lines if there is damage to the display cables or the LCD screen.

Dell monitors provide a self-test feature check (SFTC) and an integrated self-test (BIST) or integrated diagnostic (BID) tool that helps determine if the screen abnormality you are experiencing is an inherent problem with the Dell monitor or with the video card (GPU) and computer settings.

When you notice screen abnormalities like flickering, distortion, clarity issues, fuzzy or blurry image, horizontal or vertical lines, color fade, it is a good practice to isolate the monitor by running a diagnostic test on the Dell monitor.

To learn more about running a diagnostic test on your Dell monitor, see the Dell knowledge base article How to Run a Diagnostic Test on a Dell Monitor.

NOTE: Self-test feature check (SFTC) helps check if the Dell monitor is working normally as a stand-alone device. To check for screen abnormalities such as flickering, distortion, clarity issues, fuzzy or blurry image, horizontal or vertical lines, color fade, and so on, run the integrated self-test (BIST) or integrated diagnostic (BID) test.

NOTE: In certain Dell monitors, the integrated self-test (BIST) or integrated diagnostics (BID) can be run only when one or more video cables are unplugged and the Dell monitor is in self-test mode.

Dell monitors can be reset to factory default settings using the on-screen display (OSD) menu. This can be accessed using the buttons or joystick that is available on the Dell monitor. For step-by-step instructions to reset a Dell monitor to factory default settings, see the User Guide of your Dell monitor at the Dell Manuals website.

Display settings like brightness, refresh rate, resolution, and power management may affect the performance of your Dell monitor. Changing the display settings can help resolve several types of video issues.

If you find that the Dell touch-capable monitor is unresponsive to touch or touch works intermittently, you can try some common troubleshooting steps to help fix the issue.

NOTE: Connect the USB upstream cable from your Dell touch-capable monitor to a working USB port on the computer. This is essential for the touch feature to work.

If the diagnostic tests on the Dell monitor and video card (GPU) passed, it is most definitely an issue that is related to software that is installed on your computer. If the above troubleshooting steps did not resolve the issue, to restore your computer to factory defaults as a last resort.

Troubleshooting CRTs versus LCDs begins with similar steps, but diverges due to the differing natures of the two display types. The first troubleshooting steps are similar for either display type: power down the system and display and then power them back up; make sure the power cable is connected and that the outlet has power; verify that the signal cable is connected firmly to both video adapter and display and that there are no bent pins; verify that the video adapter is configured properly for the display; try the problem display on a known-good system, or try a known-good display on the problem system; and so on. Once you"ve tried the "obvious" troubleshooting steps, if the problem persists, the next step you take depends on the type of display. The following sections cover basic troubleshooting for CRTs and LCDs.

If your LCD displays no image at all and you are certain that it is receiving power and video signal, first adjust the brightness and contrast settings to higher values. If that doesn"t work, turn off the system and LCD, disconnect the LCD signal cable from the computer, and turn on the LCD by itself. It should display some sort of initialization screen, if only perhaps a "No video signal" message. If nothing lights up and no message is displayed, contact technical support for your LCD manufacturer. If your LCD supports multiple inputs, you may need to press a button to cycle through the inputs and set it to the correct one.

Unlike CRTs, where increasing the refresh rate always reduces flicker, LCDs have an optimal refresh rate that may be lower than the highest refresh rate supported. For example, a 17" LCD operating in analog mode may support 60 Hz and 75 Hz refresh. Although it sounds counterintuitive to anyone whose experience has been with CRTs, reducing the refresh rate from 75 Hz to 60 Hz may improve image stability. Check the manual to determine the optimum refresh rate for your LCD, and set your video adapter to use that rate.

First, try setting the optimal refresh rate as described above. If that doesn"t solve the problem and you are using an analog interface, there are several possible causes, most of which are due to poor synchronization between the video adapter clock and the display clock, or to phase problems. If your LCD has an auto-adjust, auto-setup, or auto-synchronize option, try using that first. If not, try adjusting the phase and/or clock settings manually until you have a usable image. If you are using an extension or longer than standard video cable, try connecting the standard video cable that was supplied with the display. Long analog video cables exacerbate sync problems. Also, if you are using a KVM switch, particularly a manual model, try instead connecting the LCD directly to the video adapter. Many LCDs are difficult or impossible to synchronize if you use a KVM switch. If you are unable to achieve proper synchronization, try connecting the LCD to a different computer. If you are unable to achieve synchronization on the second computer, the LCD may be defective. Finally, note that some models of video adapter simply don"t function well with some models of LCD.

The best way to adjust clock and phase is to use auto-adjust first. Check the utility and driver CD that came with the monitor. It may have a wizard or at least the appropriate background screens to use while adjusting phase and clock settings. If not, go to the Windows Start menu and select Shutdown. When the screen goes gray and the Windows Shutdown dialog appears, leave that dialog onscreen, but ignore it. Use the gray screen to adjust clock and phase manually. Any problems with clock and phase and any changes you make to the clock and phase settings are clearly evident on the gray screen.

Always adjust clock first. Clock is usually not a problem if you have used the auto-adjust feature of your monitor, but if you do have clock problems they will be evident as large vertical bars on your screen. Tweak the clock setting until those bars disappear. Then adjust phase. Phase problems are evident as thin black lines running horizontally across the screen. Adjust phase until the lines disappear or are minimized.

Your video card is supplying a video signal at a bandwidth that is above or below the ability of your LCD to display. Reset your video parameters to be within the range supported by the LCD. If necessary, temporarily connect a different display or start Windows in Safe Mode and choose standard VGA in order to change video settings.

This occurs when you run an LCD at other than its native resolution. For example, if you have a 19" LCD with native 1280x1024 resolution but have your display adapter set to 1024x768, your LCD attempts to display those 1024x768 pixels at full screen size, which physically corresponds to 1280x1024 pixels. The pixel extrapolation needed to fill the screen with the smaller image results in artifacts such as blocky or poorly rendered text, jaggy lines, and so on. Either set your video adapter to display the native resolution of the LCD, or set your LCD to display the lower-resolution image without stretching the display (a feature sometimes referred to as display expansion), so that pixels are displayed 1:1, which results in the lower resolution using less than the entire screen.

This is a characteristic of LCDs, particularly older and inexpensive models, caused by defective pixels. Manufacturers set a threshold number below which they consider a display acceptable. That number varies with the manufacturer, the model, and the size of the display, but is typically in the range of 5 to 10 pixels. (Better LCDs nowadays usually have zero dead pixels.) Nothing can be done to fix defective pixels. Manufacturers will not replace LCDs under warranty unless the number of defective pixels exceeds the threshold number.

Again, this is a characteristic of LCDs, particularly older and inexpensive models. The after-image occurs when the display has had the same image in one place for a long time. The after-image may persist even after you turn the display off.

Transistor-based pixels in an LCD respond more slowly than the phosphors in a CRT. The least-expensive LCDs exhibit this problem even with slow image movement, as when you drag a window. Better LCDs handle moderately fast image movement without ghosting, but exhibit the problem on fast-motion video. The best LCDs handle even fast-motion video and 3D gaming very well. The only solution to this problem is to upgrade to an LCD with faster response time.

If your monitor is not receiving power, the power cables of the monitor may have become loose and power isn"t reaching your monitor. Make sure that the monitor is securely connected to a working power source and that the cables are not frayed or pulled free from their connections.

If you have recently had a software update and your screen went dark shortly after this update, then you might have corrupt software. Sometimes corrupt software can be easily fixed by rebooting your system; restarting might trigger a better compatibility between the monitor and the software. If rebooting does not fix the problem, use the system restore function found by searching "system restore" in the windows home search, to restore your computer system to a point before the update. Alternately, try re-installing the software that is causing the problems.

If lines appear on your screen, you may have loose or faulty cables. Check the DVI or VGA cables connecting your monitor to your computer. Ensure the cables are securely connected to the correct input. If the problem persists, try using a new set of DVI or VGA cables.

If you are experiencing screen glitches a common source of this problem is outdated drivers. Check that you have the most current hardware drivers for your monitor and video card.

If lines appear on the screen, many times a bad power supply is the cause of this problem. Check to see if the power cables are securely connected to the monitor. To check for updated drivers, go to the device manager in windows and find the malfunctioning device in the list. Right-click on the device name and go to the properties window, which will display if the drivers are up to date or not. Also, make sure the power cables are connected to a working power outlet.

If there is a distorted picture, a common cause is a loose cable inside the monitor. This requires disassembly of the monitor in order to repair the problem. Check that the various internal cables are securely fastened. To see the steps to check the cables, click here.

There might be unwanted residue underneath the buttons. A common solution for eliminating residue is by taking a can of compressed air and spraying around the button. If the problem persists you might have to open up the monitor and repair it.

When set to maximum resolution and brightness, the screen may switch off to protect itself or to save power. This problem can be solved by restoring the screen to more efficient resolution and brightness settings. To change the brightness, use the brightness button on the lower right-hand side of the monitor. The brightness button will open up a menu allowing you to manage your brightness settings. Alternatively, the menu button, located next to the brightness button, will make a pop-up menu appear on the screen. If given the choice, click on the “Auto” or “Auto-Adjust” option.

If the monitor has issues turning on and off the capacitors, which give power to the monitor, may not be working properly. This results in the screen flickering on and off.

A common source for distorted colors is loose or faulty cables. Check the DVI or VGA cables connecting your monitor to your computer. Ensure the cables are securely connected to the correct input. If the problem persists, try using a new set of DVI or VGA cables.

Many times a bad power supply is a reason why color distortion occurs. Check to see if the power cables are securely connected to the monitor. Also, make sure the power cables are connecting to a working power outlet.

A loose cable inside the monitor may be causing the picture distortion. This requires disassembly of the monitor to repair the problem. Check that the various internal cables are securely fastened. To check the cables, click here.
