3.5 inch tft display 320x480 factory

ER-TFTM035-6 is 320x480 dots 3.5" color tft lcd module display with ILI9488 controller and breakout board,superior display quality,super wide viewing angle and easily controlled by MCU such as 8051, PIC, AVR, ARDUINO,ARM and Raspberry PI.It can be used in any embedded systems,industrial device,security and hand-held equipment which requires display in high quality and colorful image.

It supports 8080 8-bit /9-bit/16-bit /18-bit parallel ,3-wire,4-wire serial spi interface.Built-in microSD card slot, optional 3.5" 4-wire resistive touch panel with controller XPT2046 and capacitive touch panel with controller FT6236, so you can detect finger presses anywhere on the screen and doesn"t require pressing down on the screen with a stylus and has nice glossy glass cover . It"s optional for font chip, flash chip and microsd card. We offer two types connection,one is pin header and the another is ZIF connector with flat cable mounting on board by default and suggested. Lanscape mode is also available.

Of course, we wouldn"t just leave you with a datasheet and a "good luck!".Here is the link for 3.5"TFT Touch Shield with Libraries, EXxamples.Schematic Diagram for Arduino Due,Mega 2560 and Uno . For 8051 microcontroller user,we prepared the detailed tutorial such as interfacing, demo code and development kit at the bottom of this page.

RFI350U-AYW-DNN is a 3.5-inch diagonal IPS transmissive type 320x480 TFT LCD display module. The module features wide viewing angle thanks to the IPS panel which is one of the most popular techniques on the market now. The dimension size of this module is 54.5x83 mm, size of active area is 48.96x73.44 mm. This TFT display module uses ILI9488 driver IC which supports 8/16/18-bit MCU, 3-Line SPI interface and RGB interface + 3-SPI. This 320x480 TFT LCD module has brightness 600 cd/m2 with contrast ratio (typical value) 700:1. The module works within the temperature -20 to +70℃, storage temperature ranges from -30 to +80℃.

NMLCD-35320480-CTP-CLBis a colour active matrix LCD module incorporating amorphous silicon TFT (Thin Film Transistor). It is composed of a colour TFT-LCD panel, driver IC, FPC and a back light unit and with a Touch Panel (TP)，with a Cover Lens Bezel(CLB). The module display area contains 320 x 480 pixels. This product accords with RoHS environmental criterion.

Shenzhen SLS Industrial Co.,ltd established in 2003, is a professional LCD module manufacturer and solution provider. We have 1 full-auto COG assembly line, 2 semi-auto assembly line, backlight assembly line, no dust TP bonding line and manufacturing tech support, we can provide unique, innovative and cost effective LCD module development and manufacturing. Our product range includes: middle-small size TFT LCD, industrial capacitive touch panel... Our LCD products have been widely used in communications, GPS, Equipment, electronic audio-visual, instrumentation, household appliances, PDA and other industries.

NMLCD-35480320is a colour active matrix LCD module incorporating amorphous silicon TFT (Thin Film Transistor). It is composed of a colour TFT-LCD panel, driver IC, FPC and a back light unit and with/without a Resistive/Capacitive Touch Panel (RTP or CTP), and with/without a Cover Lens Bezel (CLB). The module display area contains 320 x 480 pixels. This product accords with RoHS environmental criterion.

Shenzhen SLS Industrial Co.,ltd established in 2003, is a professional LCD module manufacturer and solution provider. We have 1 full-auto COG assembly line, 2 semi-auto assembly line, backlight assembly line, no dust TP bonding line and manufacturing tech support, we can provide unique, innovative and cost effective LCD module development and manufacturing. Our product range includes: middle-small size TFT LCD, industrial capacitive touch panel... Our LCD products have been widely used in communications, GPS, Equipment, electronic audio-visual, instrumentation, household appliances, PDA and other industries.

The infrared touch screen is equipped with a circuit board frame in front of the display. The circuit board arranges infrared emitting tubes and infrared receiving tubes on the four sides of the screen to form a horizontal and vertical infrared matrix. When the user touches the screen, the finger will block the horizontal and vertical infrared rays passing through the position, so the position of the touch point on the screen can be determined. Any touch object can change the infrared ray on the contact to realize the touch screen operation. The infrared touch screen is not subject to current, voltage and electrostatic interference, and is suitable for some harsh environmental conditions. Its main advantages are low price, easy installation, no need for card or any other controller, and it can be applied to computers of all levels.

The main part of the resistive touch screen is a resistive thin film screen that fits well with the display surface. Two layers of OTI transparent oxide metal conductive layers are coated on the reinforced glass surface. Pressure sensing is used for control. When a finger touches the screen. The two conductive layers contact at the touch point, and the resistance changes. Signals are generated in the X and Y directions and then transmitted to the touch screen controller. The controller detects this contact and calculates the position of (x, y) and then operates according to the way of simulating the mouse. The resistive touch screen is not afraid of dust, water and dirt, and can work in harsh environments. However, because the outer layer of the composite film is made of plastic material, the explosion resistance is poor, and the service life is affected to a certain extent.

3.5 inch industrial hvga 320x480 IPS tft lcd panel touch screen diy display module This 3.5 inch TFT LCD module is portrait mode with IPS (In-Plane Switching) Panel which having the advantages of wider viewing angle of Left:80 / Right:80 / Up:80 / Down:80 degree (typical). LM035HQ10HS module can be operating at temperatures from -30℃ to 85℃; its storage temperatures range from -30℃ to 85℃.

The backlight of this 10.1 inch TFT LCD screen is composed of 42 LEDs with 21.7V backlight voltage and 120mA driving current to make it work perfectly to achieve brightness 400cd/m2. It is a landscape type 10.1" TFT LCD display with 16:9 aspect ratio and with outline dimensions 229.46*149.30*2.55 mm and active area of 216.96*135.6 mm, it can be operated at temperatures from -20 to 70 degrees, stored at temperatures from -30 to 80 degree with 30,000 hours LED lifetime. It can be used in any embedded systems, industrial devices, security and hand-held equipment which requires display in high quality and color image. It supports 4-wire serial SPI interface with optional soldering type FPC or FPC with connectors.

Maxen is a professional supplier of small and medium-size TFT LCD panels and touch screens. Our products are produced in around 7,000 square meters production area, including 5,000 square meters 100 level to 1000 level dust-free workshop. Our Company is an ISO9001 and ISO14001 certified manufacturer and qualified producer of TS16949. Our well trained 2100 employees are having rich experience in producing touch screen and TFT LCD display with 12 years experience.

This Super thinner type 10.1” LVDS TFT LCD display module can be used for applications like GPS navigation, smart home, video intercom, HMI, Tablet and etc.

2. It with 320x480 resolution , IPS/ Wide/ Free/ All view angle, 8-/ 9-/16-/18- 8080-MCU 4-lines / 3-lines SPI + 16-/18-bit RGB, ILI 9488 driver IC , 300 nits brightness, with capacitive touch panel/optical bonding .

ChengHao Display model CH350HV16A is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This model is composed of a TFT LCD panel, a driving IC, a back-light (BL), and FPC.

The driver used for this project is the ST7796S and can display 16M colors by 24 bit R.G.B. signal input. The driver is mounted on the glass and the interconnection via FPC including components to drive the display module. Support SPI/RGB/MCU/MIPI Multi-interface.

Here is the 3.5 inch TFT LCD module in 320x480 dots, 3.5 inch tft lcd display, ST7796S controller, viewing angle 12 O’clock, white white led backlight, CPU interface. Shenzhen Enrich Electronics Co.,Ltd with 4 automatic bonding COG production lines, 4 assembly and testing lines.
