one is a hardware fault, the other is a software problem. Although only these two big aspects but involved in the details of the aspect is very much, the following details about the display color abnormal possible reasons and solutions.

Monitor color is not normal, we recommend the first use of the elimination method, as far as possible to eliminate some simple problems. There are many reasons leading to the abnormal display of the display color, such as checking whether the display data line is normal, the display color control panelis not set well, poor contact, or rust of the display wire may lead to such problems.

For this kind of fault a lot of people say that the video card has a hardware fault, some people say that the picture tube was scrapped, and some people say that the driver of the video card was damaged, these views are wrong.

A kinescope-tube failure can cause this problem, but it is not irreparable – minor electric shocks, serious rewound filament power supply windings, and sometimes the visual discharge power supply resistance of a particular electron gun is miswelded or broken or the resistance value is increased.

For the first kind of fault phenomenon, some models only have a certain slight leakage of electricity between the poles, which usually need no maintenance. They only have aninstant color deviation when starting up, which can be normal in a few seconds.

For the contact pole (sometimes only leakage) fault you can only hand it over to professional maintenance personnel for maintenance, its characteristics are usually caused by the protective shutdown. For irregular deviation color fault usually as long as the relevant electron gun visual power supply resistance and peripheral components repair welding can be done.

For the power supply resistance is broken damage caused by the fault phenomenon and contact pole for full screen back sweep wire and very bright color, but it will not lead to a protective shutdown, the solution is very simple – change the same resistance value of the new resistance! Of course, if the resistance value is increased, you also have to do new processing. In the wet season, we also need to take into account the picture tube seat tube oxidation for this reason, although the resulting color deviation fault is not much, but may encounter it.

In addition, there is easier to let people detour the cause of failure – screen dust caused by too much screen white when red! This kind of fault often happens in the monitor that color temperature slants warm (a lot of monitors can set color temperature by oneself), say so, encounter white (and similar color) slants red when the fault you had better be cleaned the first screen later undertake other checks, if the fault disappears, mean you won’t because of this and “unlucky” detour. Of course, too low brightness values on some models can also cause this “fault” phenomenon.

If all of the above methods are ineffective and the display is well over five years old, we can consider the color deviation of the display caused by the aging of the electron gun to be abnormal.

Some half professionals see the two faults as a tube in life, some of the maintenance personnel to see will say adjust the contrast and the focusing extremely potentiometer and accelerate the potentiometer on the ignition coil will be good, others say it’s caused by a hardware failure or graphics driver damage of graphics, these point of failure judgment is wrong.

The aging of the kinescope and the decline, in contrast, will not cause such failure phenomenon, as for the adjustment of the collector and the acceleration of the electrode potentiometer is not correct, this is palliative, and it is difficult to adjust to a satisfactory degree, the most troublesome is that the fault will soon return, even accelerate the aging of the kinescope.

Usually use more than 2 years of the color display will appear this kind of fault, the real cause of the fault is mostly caused by the picture tube seat moisture oxidation, as long as the replacement of the original new tube seat can be troubleshoot. But some say it would be gilding the gilt by using a small piece of sandpaper to polish the protruding end of the tube to remove the oxide. In the picture tube that the author has replaced the tube seat, some of them do have some oxides on the tube foot, but these oxides are missing from the original tube seat to the tube foot, which can be removed with a brush. Up to now, the author did not see the tube was oxidized, but due to excessive force and make the tube leakage and damage the picture tube is encountered a few cases, so we do not use sandpaper to burnish, so as not to appear “death” damage!

If the replacement of the tube seat is not effective will replace the FBT, but in this work, the author suggests you had better find professional personnel! In addition, some types of visual amplifier parts of the circuit are more special, sometimes after the fault will also cause the image blur. But at this time usually the brightness and line, field amplitude are also abnormal, for this kind of fault point the author recommends that you deliver professional personnel to deal with! If the color display is not a brand-name product and the use of a very long time, then the author suggests that you find a professional electrical maintenance department to replace the work of the tube seat, so as to avoid the occurrence of pipe neck leakage and other accidents after the responsibility!

1) the image is clear at the beginning of starting up, but the color of the display is abnormal as the use time is prolonged and the display becomes increasingly blurred;

2) the image occasionally becomes blurry in use, but it can return to normal soon. However, it becomes more serious and frequent after several days or months of use.

Some people think that this kind of fault is the problem of the line circuit of the monitor — it may be the poor thermal stability of the line tube, the reverse diode, reverse capacitor, and other components or the result of virtual welding. This is completely wrong because none of these components can affect the clarity of the image.

The real failure point of the type 1 fault phenomenon is usually due to the aging of the focusing knob of the FBT. You can try to replace an FBT first. Of course, if the monitor has been in use for more than six years, then we need to take into account the possibility of tube aging. In addition, it may be the tube seat of the picture tube and the large area of the negative copper foil leakage phenomenon caused by the displacer (after analysis like design problems), so sometimes into a maintenance dilemma after the replacement of a genuine tube seat try.

The type 2 fault phenomenon, is usually caused by the poor quality of the picture tube holder. You can solve the problem by replacing it with a new one.

A lot of people think this is the mains voltage of the mains electricity is the insufficient or unstable cause, some “master” can say even because of the lamps and lanterns that contains electronic ballast or electromechanical kind electric appliance brings color to show the interference of power source, somebody says the hardware fault that the video card produced is caused by. In fact, these views are wrong, because the display voltage requirements are not very strict – most of the current color display can be in the 100V ~ 240V power supply voltage under normal operation. As for other electrical appliances that will cause interference is even more impossible, after all, color display use is not mutual inductance stabilized voltage power supply, and other electrical appliances even if the interference will not be screen flicker!

The real fault causes of the first two kinds of faults are usually caused by the virtual welding of some components in the line circuit or the reduction of the +300V filter capacitance at the power supply. The latter possibility is not very high – only in a few models and its more serious loss of volume will cause the human eye to distinguish the flicker. In addition, the circuit of the visual amplifier power supply part of some models is special, and sometimes a component of this part may also cause this fault. Of course, if you set your monitor’s resolution and refresh rate too high or too low, you can set the resolution and refresh rate to the middle value.

There is also a video card or monitor driver there are bugs, so you should first update the driver to try. If the above treatment is not effective, you can focus on checking whether the accelerator voltage and high voltage generated by the FBT are normal, because sometimes these two abnormal voltages can also cause such a phenomenon.

The poor contact of the video card usually causes the failure of starting up and there is an alarm sound or the system is unstable resulting in a crash and other failures. The reason for the poor contact of the graphics card is that the gold finger of the graphics card is oxidized, dust, the quality of the graphics card is poor or the baffle of the case has a problem. For the golden finger oxidation caused by poor contact, can use an eraser to wipe the golden finger to solve; For dust caused by poor contact, general removal of dust can be solved; For the hardware quality caused by poor contact, usually through the replacement method to detect, generally replace the video card to solve; For the case baffle problem caused by poor contact, usually the video card can not be fully inserted into the video card slot, can be replaced by the case to eliminate.

Compatibility failure will usually cause the computer can not to start up and alarm sound, the system is not stable crash or screen abnormal miscellaneous phenomenon. Display card compatibility fault generally occurs in the computer just installed or upgrade, more in the motherboard and display card is not compatible or motherboard slot and display card gold finger can not completely contact. The video card compatibility fault usually USES the replacement method to detect, generally USES the replacement video card to troubleshoot the fault.

The failure of the components of the graphics card will usually cause the failure of the computer can not startup, the system is not stable crash, flower screen, and other fault phenomena. The damage of graphics components generally includes the damage of graphics chip, BIOS, memory, capacitance, or field-effect tube. For the damage and failure of graphics card components, it is generally necessary to carefully measure the signals in the graphics card circuit to judge the damaged components. After finding the damaged components, replace them.

Due to the graphics chip will produce a lot of heat when working, so need to have a better cooling condition, if the cooling fan damage will lead to graphics card overheating can not work normally. The overheat fault of the graphics card usually causes the system unstable crash, flower screen, and other fault phenomena. Video card overheating as long as the replacement of the cooling fan.

The failure of the graphics driver usually causes the system unstable crash, flower screen, text image graphics card is not complete, and other fault phenomena. The video driver’s fault mainly includes the loss of the video driver, the video driver is incompatible with the system, the video driver is damaged, and the video driver cannot be installed. For the video card, driver failure generally first enter the “device manager” to see whether there is a video card driver, if not, re-install. If so, but the graphics driver has a “!”, the video card driver is not installed, the driver version is not correct, the driver and the system are not compatible. Generally, remove the video card driver reinstall, if installed after there are “!”, you can download the new version of the driver installation. If you cannot install a graphics driver, there is usually a problem with the driver or with the registry.

CMOS setup failure is caused by the error of displaying related options in CMOS. Common CMOS setup failures mainly include: integrated graphics card motherboard, CMOS graphics card shielding options setting error; For example, the “AGP Driving Control” option is incorrectly set (usually “AUTO”), “AGP Aperture Size” option is incorrectly set, and “FAST Write Supported” option is incorrectly set.CMOS error is generally modified by loading the default BIOS value.

If the fault is serious, the maintenance requires that you must have certain hands-on ability and professional knowledge, so the author suggests that if you still have not been repaired after eliminating the simple cause of the fault, please deliver it to the electrical maintenance department for treatment. Sometimes some magnetic objects (such as some low power box or ADSL cat power supply, etc.) placed near the display will cause a certain Angle flicker on the screen, so when this phenomenon to try to clear the display around the objects to see, usually the problem can be solved.

STONE provides a full range of 3.5 inches to 15.1 inches of small and medium-size standard quasi TFT LCD module, LCD display, TFT display module, display industry, industrial LCD screen, under the sunlight visually highlight TFT LCD display, industrial custom TFT screen, TFT LCD screen-wide temperature, industrial TFT LCD screen, touch screen industry. The TFT LCD module is very suitable for industrial control equipment, medical instruments, POS system, electronic consumer products, vehicles, and other products.

A monitor is connected to the computer but does not display anything. Use the steps in this document to resolve this issue or to determine if the monitor is defective.

With the monitor plugged in, press the power button on the monitor. There should be a power indicator light located on the monitor case. What happens to the light?

If power light remains off when you press the power button, either the monitor is not receiving power or the monitor is defective. Check all of the following items before attempting to service or replace the monitor:

If a message appears on the monitor, the display panel is working and the problem is related to the video signal. For further troubleshooting steps, see Message about No Signal, Signal out of Range, Sleep, or Power Save.

Check for bent or broken connector pins or broken pins that have become lodged inside the holes of the video connector on the computer. With the monitor and computer off, straighten bent pins with a small metal tube, like the tip of an empty mechanical pencil or the tip of a retracted pen. If any of the pins have broken off from the cable and are stuck in the small holes of the video connector (on the computer), remove the broken pins using a metal sewing pin (or similar metal pin that is thin and has a point).

Connect another video cable to the computer and monitor. If possible use a different cable. For example, if your monitor has an HDMI connector and a DVI connector, use the other cable type if possible. If not, use a new cable of the same type.

If the monitor remains blank, connect the monitor to another computer using a different cable to determine if the monitor is bad. Skip to the Step connect the monitor to another computer.

Find the native display resolution for your monitor in the User Manual or in the product specifications for the monitor model. If you are unable to find the native display resolution for your monitor model, temporarily use 1024x768 for troubleshooting purposes.

If you are satisfied with the new display settings, click Yes on the Monitor Settings windows. If you are not satisfied or if the screen just goes black, wait: Windows sets the screen back to the way it was before. Try another setting until you find a display configuration that is compatible with the monitor and meets your needs.

If the native resolution is not available, download and install updated video driver software for your computer. Updating the video driver software can add more resolutions (graphics modes).

If the monitor works, the video hardware on the original computer is likely to be the source of the problems. You can try connecting the original computer to another monitor that works to update its video drivers.

Let us start with the basics first; refresh the knowledge about TN and LCD displays in general, later we will talk about TFTs (Thin Film Transistors), how they differ from regular monochrome LCD displays. Then we will go on to the ghosting effect, so we will not only discuss the technology behind the construction of the TFT, but also some phenomena, like the ghosting effect, or grayscale inversion, that are important to understand when using an LCD TFT display.

Next, we will look at different technologies of the TFT LCD displays like TN, IPS, VA, and of course about transmissive and transflective LCD displays, because TFT displays also can be transmissive and transflective. In the last part we will talk about backlight.

Let us start with a short review of the most basic liquid crystal cell, which is the TN (twisted nematic) display. On the picture above, we can see that the light can be transmit through the cell or blocked by the liquid crystal cell using voltage. If you want to learn more about monochrome LCD displays and the basics of LCD displays, follow this link.

What is a TFT LCD display and how it is different from a monochrome LCD display? TFT is called an active display. Active, means we have one or more transistors in every cell, in every pixel and in every subpixel. TFT stands for Thin Film Transistor, transistors that are very small and very thin and are built into the pixel, so they are not somewhere outside in a controller, but they are in the pixel itself. For example, in a 55-inch TV set, the TFT display contains millions of transistors in the pixels. We do not see them, because they are very small and hidden, if we zoom in, however, we can see them in every corner of each pixel, like on the picture below.

On the picture above we can see subpixels, that are basic RGB (Red, Green, Blue) colors and a black part, with the transistors and electronic circuits. We just need to know that we have pixels, and subpixels, and each subpixel has transistors. This makes the display active, and thus is called  the TFT display. TFT displays are usually color displays, but there are also monochrome TFT displays, that are active, and have transistors, but have no colors. The colors in the TFT LCD display are typically added by color filters on each subpixel. Usually the filters are RGB, but we also have RGBW (Red, Green, Blue, White) LCD displays with added subpixels without the filter (White) to make the display brighter.

What is interesting, the white part of the RGB and RGBW screen will look exactly the same from a distance, because the lights are mixed and generate white light, but when we come closer to the screen, we will not see white light at all.

Going a little bit deeper, into the TFT cell, there is a part inside well known to us from the monochrome LCD display Riverdi University lecture. We have a cell, liquid crystal, polarizers, an ITO (Indium Tin Oxide) layer for the electrodes, and additionally an electronic circuit. Usually, the electronic circuit consists of one transistor and some capacitors to sustain the pixel state when we switch the pixel OFF and ON. In a TFT LCD display the pixels are much more complicated because apart from building the liquid crystal part, we also need to build an electronic part.

That is why TFT LCD display technologies are very expensive to manufacture. If you are familiar with electronics, you know that the transistor is a kind of switch, and it allows us to switch the pixel ON and OFF. Because it is built into the pixel itself, it can be done very quickly and be very well controlled. We can control the exact state of every pixel not only the ON and OFF states, but also all the states in between. We can switch the light of the cells ON and OFF in several steps. Usually for TFT LCD displays it will be 8-bit steps per color, so we have 256 steps of brightness for every color, and every subpixel. Because we have three subpixels, we have a 24-bit color range, that means over 16 million combinations, we can, at least theoretically, show on our TFT LCD display over 16 million distinct colors using RGB pixels.

Now that we know how the TFT LCD display works, we can now learn some practical things one of which is LCD TFT ghosting. We know how the image is created, but what happens when we have the image on the screen for a prolonged time, and how to prevent it. In LCD displays we have something called LCD ghosting. We do not see it very often, but in some displays this phenomenon still exists.

If some elements of the picture i.e., your company logo is in the same place of the screen for a long period of time, for couple of weeks, months or a year, the crystals will memorize the state and later, when we change the image, we may see some ghosting of those elements. It really depends on many conditions like temperature and even the screen image that we display on the screen for longer periods of time. When you build your application, you can use some techniques to avoid it, like very rapid contrast change and of course to avoid the positioning the same image in the same position for a longer time.

You may have seen this phenomenon already as it is common in every display technology, and even companies like Apple put information on their websites, that users may encounter this phenomenon and how to fix it. It is called image ghosting or image persistence, and even Retina displays are not free of it.

Another issue present in TFT displays, especially TN LCD displays, is grayscale inversion. This is a phenomenon that changes the colors of the screen according to the viewing angle, and it is only one-sided. When buying a TFT LCD display, first we need to check what kind of technology it is. If it is an IPS display, like the Riverdi IPS display line, then we do not need to worry about the grayscale inversion because all the viewing angles will be the same and all of them will be very high, like 80, 85, or 89 degrees. But if you buy a more common or older display technology type, like the TN (twisted nematic) display, you need to think where it will be used, because one viewing angle will be out. It may be sometimes confusing, and you need to be careful as most factories define viewing direction of the screen and mistake this with the greyscale inversion side.

On the picture above, you can see further explanation of the grayscale inversion from Wikipedia. It says that some early panels and also nowadays TN displays, have grayscale inversion not necessary up-down, but it can be any angle, you need to check in the datasheet. The reason technologies like IPS (In-Plane Switching), used in the latest Riverdi displays, or VA, were developed, was to avoid this phenomenon. Also, we do not want to brag, but the Wikipedia definition references our website.

We know already that TN (twisted nematic) displays, suffer from grayscale inversion, which means the display has one viewing side, where the image color suddenly changes. It is tricky, and you need to be careful. On the picture above there is a part of the LCD TFT specification of a TN (twisted nematic) display, that has grayscale inversion, and if we go to this table, we can see the viewing angles. They are defined at 70, 70, 60 and 70 degrees, that is the maximum viewing angle, at which the user can see the image. Normally we may think that 70 degrees is better, so we will choose left and right side to be 70 degrees, and then up and down, and if we do not know the grayscale inversion phenomena, we may put our user on the bottom side which is also 70 degrees. The viewing direction will be then like a 6 o’clock direction, so we call it a 6 o’clock display. But you need to be careful! Looking at the specification, we can see that this display was defined as a 12 o’clock display, so it is best for it to be seen from a 12 o’clock direction. But we can find that the 12 o’clock has a lower viewing angle – 60 degrees. What does it mean? It means that on this side there will be no grayscale inversion. If we go to 40, 50, 60 degrees and even a little bit more, probably we will still see the image properly. Maybe with lower contrast, but the colors will not change. If we go from the bottom, from a 6 o’clock direction where we have the grayscale inversion, after 70 degrees or lower we will see a sudden color change, and of course this is something we want to avoid.

To summarize, when you buy older technology like TN and displays, which are still very popular, and Riverdi is selling them as well, you need to be careful where you put your display. If it is a handheld device, you will see the display from the bottom, but if you put it on a wall, you will see the display from the top, so you need to define it during the design phase, because later it is usually impossible or expensive to change the direction.

We will talk now about the other TFT technologies, that allow us to have wider viewing angles and more vivid colors. The most basic technology for monochrome and TFT LCD displays is twisted nematic (TN). As we already know, this kind of displays have a problem with grayscale inversion. On one side we have a higher retardation and will not get a clear image. That is why we have other technologies like VA (Vertical Alignment), where the liquid crystal is differently organized, and another variation of the TFT technology – IPS which is In-Plane Switching. The VA and IPS LCD displays do not have a problem with the viewing angles, you can see a clear image from all sides.

Nowadays all TV sets, tablets and of course mobile phones are IPS or VA. You can turn them around and see the image clear from all sides. But, for monitor applications the TN technology is still widely used, because the monitor usually is in front of you and most of the time you look directly at it, from top, left or right side, but very rarely from the bottom, so the grayscale inversion viewing angle can be placed there. This technology still is very practical because it is affordable and has some advantages for gamers because it is very fast.

Apart from the different organization of the liquid crystals, we also organize subpixels a little bit differently in a VA and IPS LCD displays. When we look closer at the TN display, we will just see the subpixels with color filters. If we look at the VA or IPS display they will have subpixels of subpixels. The subpixels are divided into smaller parts. In this way we can achieve even wider viewing angles and better colors for the user, but of course, it is more complicated and more expensive to do.

The picture above presents the TN display and grayscale inversion. For IPS or VA technology there is no such effect. The picture will be the same from all the sides we look so these technologies are popular where we need wide viewing angles, and TN is popular where we don’t need that, like in monitors. Other advantages of IPS LCD displays are they give accurate colors, and wide viewing angles. What is also important in practice, in our projects, is that the IPS LCD displays are less susceptible to mechanical force. When we apply mechanical force to the screen, and have an optically bonded touch screen, we push the display as well as squeeze the cells. When we have a TN display, every push on the cell changes the image suddenly, with the IPS LCD displays with in-plane switching, different liquid crystals organization, this effect is lesser. It is not completely removed but it is much less distinct. That is another reason IPS displays are very popular for smartphones, tablets, when we have the touchscreens usually optically bonded.

If we wanted to talk about disadvantages, there is a question mark over it, as some of them may be true, some of them do not rely on real cases, what kind of display, what kind of technology is it. Sometimes the IPS displays can have higher power consumption than others, in many cases however, not. They can be more expensive, but not necessarily. The new IPS panels can cost like TN panels, but IPS panels definitely have a longer response time. Again, it is not a rule, you can make IPS panels that are very fast, faster than TN panels, but if you want the fastest possible display, probably the TN panel will be the fastest. That is why the TN technology is still popular on the gaming market. Of course, you can find a lot of discussions on the internet, which technology is better, but it really depends on what you want to achieve.

Now, let us look at the backlight types. As we see here, on the picture above, we have four distinct types of backlight possible. The most common, 95 or 99 per cent of the TFT LCD displays on the market are the transmissive LCD display type, where we need the backlight from the back. If you remember from our Monochrome LCD Displays lecture, for transmissive LCD displays you need the backlight to be always on. If you switch the backlight off, you will not see anything. The same as for monochrome LCD displays, but less popular for TFT displays, we have the transflective LCD display type. They are not popular because usually for transflective TFT displays, the colors lack in brightness, and the displays are not very practical to use. You can see the screen, but the application is limited. Some transflective LCD displays are used by military, in applications where power consumption is paramount; where you can switch the backlight off and you agree to have lower image quality but still see the image. Power consumption and saving energy is most important in some kind of applications and you can use transflective LCD displays there. The reflective type of LCD displays are almost never used in TFT. There is one technology called Low Power Reflective Displays (LPRD) that is used in TFT but it is not popular. Lastly, we have a variation of reflective displays with frontlight, where we add frontlight to the reflective display and have the image even without external light.

Just a few words about Low Power Reflective Displays (LPRD). This kind of display uses environmental light, ambient light to reflect, and produce some colors. The colors are not perfect, not perfectly clear, but this technology is becoming increasingly popular because it allows to have color displays in battery powered applications. For example, a smartwatch would be a case for that technology, or an electrical bike or scooter, where we can not only have a standard monochrome LCD display but also a TFT LCD color display without the backlight; we can see the image even in
