आपके स्मार्टफोन की डिस्प्ले के बारे में आप कितना जानते हैं? डिस्प्ले के नाम जैसे कि AMOLED, OLED, LCD, TFT के बारे में आप कितना विस्तार से जानते हैं? इनके नाम बहुत छोटे हैं, लेकिन इनमें से कौन-सा बेहतर है, किस रिफ्रेश रेट के साथ आता है, रेज़ॉल्यूशन कितना है इन सब सवालों को जानकर यदि आप अपने लिए स्मार्टफोन चुनना चाहते हैं तो आपके इन सभी प्रश्नों के उत्तर मिलेंगे यहाँ।

पिछले कुछ सालों में स्मार्टफोन की डिस्प्ले काफी बेहतर हुई हैं। लेकिन प्रत्येक स्मार्टफोन डिस्प्ले के साथ जो शार्ट-फॉर्म एक संक्षिप्त नाम जुड़ता है, जैसे कि AMOLED, LCD, इत्यादि वो केवल नाम नहीं बल्कि अपने आप में एक तकनीक है। स्मार्टफोन पर लगे पैनल AMOLED, OLED, LED, LCD, IPS, TFT, LTPS, इत्यादि होते हैं। ये सभी पूर्णत: अलग होते हैं।

पहले ही इतने टाइप के पैनल मौजूद हैं, ऐसे में स्मार्टफोन निर्माता द्वारा फैंसी नामों का इस्तेमाल जैसे कि Apple द्वारा Super Retina XDR और Samsung द्वारा Dynamic AMOLED ग्राहकों के बीच भ्रम या असमंजस को और बढ़ा देता है।

डिस्प्ले के टाइप तो बहुत सारे हैं जैसे कि TFT, LTPS, AMOLED, OLED, IPS, LCD इत्यादि। लेकिन इन दिनों TFT, LTPS जैसी डिस्प्ले काफी कम हो गयीं हैं। किफ़ायती दामों पर और मिड-रेंज में आने वाले फोनों में आपको IPS LCD डिस्प्ले मिलेगी। लेकिन इन सबका विस्तार से समझें, तो मतलब क्या है ?

अगर संक्षिप्त रूप से और आसान भाषा में समझें तो दो तरह की टेक्नोलॉजी- एलसीडी (LCD) और ओलेड (OLED) बाज़ार में आ रहीं हैं। प्रत्येक में कुछ विभिन्न प्रकार और जनरेशन हैं जो बाकी के स्क्रीन टाइप शार्ट फॉर्म को बनाती हैं। इसी तरह टेलीविज़न की दुनिया में भी अलग स्क्रीन टाइप उपलब्ध हैं जैसे कि LED, QLED, miniLED – ये सब दरसअल एलसीडी (LCD) तकनीक के ही अलग अलग रूप हैं जिनमें थोड़ी विविधताएं हैं।

LCD का मतलब या फुल फॉर्म है लिक्विड क्रिस्टल डिस्प्ले (Liquid Crystal Display)। इसमें लिक्विड क्रिस्टल्स की एक श्रंखला दी जाती है जिसके पीछे एक बैकलाइट होती है। इस डिस्प्ले टाइप का हर जगह आसानी से उपलब्ध होना और कम दामों में इसका निर्माण इसे स्मार्टफोनों के लिए एक प्रचलित विकल्प या पसंद बनाता है।

स्मार्टफोनों में आपको दोनों डिस्प्ले TFT और IPS मिलती हैं। TFT का फुल फॉर्म है – Thin Film Transistor, जो LCD का ही एक बेहतर या एडवांस्ड वर्ज़न है, जो एक एक्टिव मैट्रिक्स (active matrix) का इस्तेमाल करता है। active matrix का अर्थ है कि प्रत्येक पिक्सेल एक अलग ट्रांजिस्टर और कपैसिटर से जुड़ा होता है।

TFT डिस्प्ले का सबसे बड़ा फायदा यही है कि इसके प्रोडक्शन में तुलनात्मक कम खर्च होता है और इसमें असल LCD के मुकाबले ज्यादा कॉन्ट्रास्ट मिलता है। वहीं TFT LCD में नुकसान ये है कि इन्हें रेगुलर LCD प्रकारों के मुकबाले ज्यादा एनर्जी यानि बैटरी चाहिए, इनके व्यूिंग एंगल और रंग भी इतने अच्छे नहीं होते। इन्हीं सब कारणों से बाकी डिस्प्ले विकल्पों की गिरती कीमतों के कारण अब TFT डिस्प्ले का इस्तेमाल स्मार्टफोनों में नहीं किया जाता।

TFT(Thin Film Transistor) – ये भी LCD डिस्प्ले का ही एक प्रकार है जिसमें नीचे एक पतली सेमीकंडक्टर की परत होती है जो हर एक पिक्सल पर रंगों को नियंत्रित करने का काम करता है। इसका और AMOLED में आने वाले AM यानि कि active matrix का काम लगभग एक ही है।

LTPS(Low Temperature PolySilicon) – ये भी Si (amorphous silicon) तकनीक पर आधारित TFT का ही वैरिएंट है जिसमें आपको हाई रेज़ॉल्यूशन मिलता है और ऊर्जा यानि कि पॉवर साधारणत: TFT से कम लेता है।

IGZO(Indium Gallium Zinc Oxide) – ये भी एक सेमिकंडक्टर मैटेरियल है जो डिस्प्ले के नीचे लगी फिल्म में इस्तेमाल होता है और आजकल a semiconductor material used in TFT films, which also allows higher resolutions and lower power consumption, and sees action in different types of LCD screens (TN, IPS, VA) and OLED displays

LTPO( Low Temperature Polycrystaline Oxide) – इस टेक्नोलॉजी को Apple ने डेवेलप किया है और इसे वर्तमान समय में OLED और LCD दोनों तरह की स्क्रीन में इस्तेमाल किया जाता है। इसमें LTPS और IGZO दोनों तकनीकों का इस्तेमाल मिलाकर किया जाता है और नतीजा होता है – डिस्प्ले द्वारा पॉवर का कम इस्तेमाल। ये Apple Watch 4 और Galaxy S21 Ultra में आयी है।

IPS तकनीक को In-Plane Switching तकनीक कहते हैं। IPS टेक्नोलॉजी ने सबसे पहले आयी LCD डिस्प्ले में आने वाली समस्या को दूर किया जिसमें TN तकनीक का इस्तेमाल होता था और इसमें साइड से देखने पर रंग बहुत ख़राब नज़र आते थे। ये कमी ज़्यादातर सस्ते स्मार्टफोन और टैबलेटों में नज़र आया करती थी।

PLS (Plane to Line Switching) – PLS और IPS के नाम या उनके फुल फॉर्म लगभग एक ही जैसे लगते हैं। लेकिन इसमें आश्चर्य की कोई बात नहीं है क्योंकि इनका मुख्य कार्य भी एक समान ही है। PLS टेक्नोलॉजी को Samsung Display द्वारा बनाया गया है और IPS डिस्प्ले की ही तरह इसकी विशेषता भी डिस्प्ले पर अच्छे रंग दर्शाना और बेहतर व्यूइंग एंगल दिखाना ही हैं। लेकिन इसमें OLED और LCD/VA डिस्प्ले के मुकाबले कॉन्ट्रास्ट थोड़ा कम है।

Samsung Display का कहना है कि PLS पैनलों के उत्पादन में लागत कम लगती है, ब्राइटनेस लेवल अच्छा मिलता है और प्रतियोगी कंपनी LG Display के IPS पैनलों के मुकाबले व्यूइंग एंगल भी काफी अच्छे मिलते हैं। अंतत: PLS पैनल का उपयोग किया जाए या IPS पैनल का इस्तेमाल करें, ये पूरी तरह से स्मार्टफोन निर्माताओं पर निर्भर करता है।

AMOLED की फुल फॉर्म – एक्टिव मैट्रिक्स ऑर्गेनिक लाइट एमिटिंग डायोड (Active Matrix Organic Light-Emitting Diode) है। हालांकि ये सुनने में बहुत मुश्किल नाम लग रहा होगा, लेकिन ये है नहीं। हम पहले ही TFT LCD टेक्नोलॉजी में एक्टिव मैट्रिक्स के बारे में पढ़ चुके हैं और अब रहा OLED, तो ये केवल एक पतली फिल्म वाली डिस्प्ले तकनीक है और कुछ नहीं।

OLED को- Organic Light Emitting Diode कहते हैं। एक OLED डिस्प्ले electroluminescent मैटीरियल की पतली शीट से बनी होती है, जिसका सबसे बड़ा फायदा यही है कि ये अपनी रौशनी खुद पैदा करते हैं और इन्हें बैकलाइट की ज़रुरत नहीं पड़ती, जिससे ऊर्जा या बिजली की ज़रुरत कम पड़ती है। यही OLED स्क्रीन जब स्मार्टफोन या टीवी के लिए उपयोग होती है तो इसे ज़्यादातर AMOLED डिस्प्ले के नाम से जाना जाता है।

पिक्सल डेंसिटी की बात करें तो, 2010 में iPhone 4 के लॉन्च के समय Apple का मुख्य आकर्षण यही था। इस स्मार्टफोन डिस्प्ले में कंपनी ने LCD डिस्प्ले का इस्तेमाल किया। इस LCD पैनल ((LED, TFT, और IPS) को हाई रेज़ॉल्यूशन (उस समय पर 960 X 640 पिक्सल्स) के साथ Retina Display का नाम दिया। इस फ़ोन में 3.5 इंच की डिस्प्ले थी।

उस समय पर Apple के मार्केटिंग डिपार्टमेंट ने Retina Display नाम इसलिए चुना क्योंकि कंपनी के अनुसार एक निश्चित दूरी से हमारी या किसी भी इंसान की आंखें अलग-अलग पिक्सल में फर्क नहीं कर पाती। iPhones के केस में, ये नाम तब इस्तेमाल होता था जब फ़ोन की डिस्प्ले पर 300 ppi (pixel per inch) से ज्यादा होती थी।

तब से, अन्य स्मार्टफोन बनाने वाली कंपनियों ने भी यही तरीका अपनाया और हाई रेज़ॉल्यूशन वाले पैनलों को अपनाना शुरू कर दिया। जबकि iPhone 12 Mini में 476 dpi और Sony Xperia 1 में 643 dpi मिलती है।

जब सबने हाई रेज़ॉल्यूशन के साथ डिस्प्ले लेना आरम्भ कर दिया, फिर Apple ने खुद को भीड़ में अलग करने के लिए अपने प्रीमियम स्मार्टफोनों में इस्तेमाल होने वाली OLED डिस्प्ले को “Super Retina” का नाम दे दिया। ये डिस्प्ले iPhone X और उसके बाद आने वाले फोनों में आयी है। ये डिस्प्ले हाई कॉन्ट्रास्ट रेट और डिस्प्ले पर रंगों की सटीकता के लिए जानी जाती है, और ऐसी ही स्क्रीन Samsung के S-सीरीज़ के स्मार्टफोनों में भी आप देख सकते हैं।

इसके बाद कंपनी ने iPhone 11 Pro के साथ डिस्प्ले का नया नाम भी लॉन्च किया – “Super Retina XDR”। इसमें भी वही OLED पैनल का उपयोग किया गया है, लेकिन इसे पैनल का निर्माण Samsung Display या LG Display द्वारा हुआ है। इसमें आपको 2,000,000:1 रेश्यो के साथ और भी बेहतर कॉन्ट्रास्ट लेवल और 1200 nits की ब्राइटनेस मिलते हैं और ये ख़ासकर HDR कंटेंट के लिए अनुकूल हैं।

वहीं iPhone XR और iPhone 11 के ग्राहकों को भी खुश रखने के लिए कंपनी ने इनमें आने वाले LCD पैनल को “Liquid Retina” का नाम दे दिया। बाद में यही डिस्प्ले कंपनी स्टैण्डर्ड के अनुसार बेहतर रेज़ॉल्यूशन और सही रंगों के साथ iPad Pro और iPad Air मॉडल में भी आया।

अंतरराष्ट्रीय प्रणाली या सिस्टम में Nit या कैंडेला प्रति वर्ग मीटर (candela per square meter), जलने या निकलने वाली रौशनी की तीव्रता या गहनता (intensity) को मापने की यूनिट है। अधिकतर स्मार्टफोन, टैबलेट, मॉनिटर के बारे में जब हम बात करते हैं तो ये यूनिट बताती है कि डिस्प्ले कितना ब्राइट है। इसकी वैल्यू जितनी ज्यादा होगा, डिस्प्ले पर पिछले से पड़ने वाली रौशनी की तीव्रता भी उतनी ही ज्यादा होगी।

टेलीविज़न की दुनिया में, miniLED के बारे में हम जान चुके हैं और ये फ़ीचर या तकनीक टीवी में हम देखते ही आ रहे हैं। इसमें बैकलाइट में लाइटिंग ज़ोन का नंबर बढ़ा दिया जाता है। लेकिन अब अफवाहों और कई ख़बरों के अनुसार स्मार्टफोनों और स्मार्टवॉच में भी कंपनियां microLED टेक्नोलॉजी जल्दी ही लेकर आ सकती हैं। ये टेक्नोलॉजी या पैनल LCD/LED से काफी अलग है क्योंकि ये OLED डिस्प्ले की तरह ही बारीकियों के साथ अच्छी पिक्चर क्वॉलिटी देती है।

microLED डिस्प्ले में हर एक सब-पिक्सल में एक अलग रौशनी देने वाला डायोड होता है – अधिकतर ये एक लाल, हरे और नीले डायोड का एक सेट होता है जो एक डॉट के लिए होता है । माना जा रहा है कि microLED में इस बार किसी तरह की अजैविक (inorganic) मैटेरियल का इस्तेमाल होगा जैसे कि gallium nitride (GaN)।

खुद अपनी रौशनी छोड़ने वाला पिक्सल यानि कि self-emitting light जैसी तकनीक अपनाने के साथ, microLED डिस्प्ले में भी बैकलाइट की ज़रूरत नहीं होती। इसमें भी आपको OLED जैसे ही हाई कॉन्ट्रास्ट के साथ पिक्चर देखने को मिलेंगी और साथ ही इसमें ऑर्गेनिक डायोड की तरह स्क्रीन बर्न-इन जैसी समस्याओं का डर भी नहीं है।

वहीँ इनकी ख़ामियों की बात करें तो, इनको बनाने में काफी ज़्यादा लागत लगती है और कॉम्पोनेन्ट की पूर्ती करने वाली कंपनियां भी सीमित ही हैं। इनमें Samsung Display, LG Display और तीसरे नंबर पर चीन की इलेक्ट्रॉनिक्स कंपनी BOE और कुछ एक जो OLED की मांग को पूरा करते हैं। जबकि LCD पैनल बनाने वाली काफी कम्पनियां हैं।

इसके अलावा एक और बात जो हम यहां जोड़ना चाहते हैं, समय के साथ OLED स्क्रीन के ऑर्गेनिक डायोड अपनी चमक या कहें कि योग्यता खो देते हैं और ये तब होता है जब एक ही तस्वीर ज्यादा समय तक डिस्प्ले होती है। इसे कपनियां “burn-in” का नाम देती हैं।

This website is using a security service to protect itself from online attacks. The action you just performed triggered the security solution. There are several actions that could trigger this block including submitting a certain word or phrase, a SQL command or malformed data.

AMOLED नाम से आप यह समझ पाएंगे की यह टेलिविजन में इस्तेमाल होनी वाली OLED डिस्प्ले टेक्नोलॉजी का ही एक वेरिएंट है। सबसे पहले LED का मतलब जानते हैं। इसका मतलब Light Emitting Diode है। इसके बाद O का मतलब होता है Organic और AM का मतलब होता है Active Matrix जो किसी भी पिक्सल को बेहतर क्वालिटी देने में सक्षम होता है। AMOLED में OLED डिस्प्ले की सभी खासियतें जैसे कलर रिप्रोडक्शन, बेहतर बैटरी लाइफ, हाई ब्राइटनेस और शार्पनेस होती हैं। इसके अलावा AMOLED डिस्प्ले में TFT यानी थिन फिल्म ट्रांजिस्टर भी शामिल होता है जो पिक्सल को सही दिशा में भेजने के पूरे प्रोसेस को आसान और स्मूद बना देता है। वहीं, एक Active Matrix की मदद से TFT को अलग-अलग पिक्सल को ऑपरेट करने का कंट्रोल मिल जाता है।

LCD की बात करें तो यह स्मार्टफोन्स में सबसे ज्यादा देखने को मिलता है। इसका मतलब Liquid Crystal Display है। LCD डिस्प्ले में एक डेडिकेटड व्हाइट बैकलाइट होती है। यह ब्लू टिंट के साथ आता है। क्योंकी व्हाइट लाइट सभी कलर्स का मिश्रण होता है। इसके अलावा LCD डिस्प्ले में एक्टिव और पैसिव मैट्रिक्स दोनों दिया गया होता है। किस फोन में कौन सा मैट्रिक्स दिया जाएगा यह उसकी जरुरत और कीमत पर निर्भर करता है।

The world of smartphones has been busy for the past few months. There have been numerous revolutionary launches with groundbreaking innovations that have the capacity to change the course of the smartphone industry. But the most important attribute of a smartphone is the display, which has been the focus for all prominent players in the mobile phone industry this year.

Samsung came up with its unique 18:5:9 AMOLED display for the Galaxy S8. LG picked up its old trusted IPS LCD unit for the G6’s display. These display units have been familiar to the usual Indian smartphone buyer. Honor, on the other hand, has just unveiled the new Honor 8 Pro for the Indian market that ships with an LTPS LCD display. This has led to wonder how exactly is this technology different from the existing ones and what benefits does it give Honor to craft its flagship smartphone with. Well, let’s find out.

The LCD technology brought in the era of thin displays to screens, making the smartphone possible in the current world. LCD displays are power efficient and work on the principle of blocking light. The liquid crystal in the display unit uses some kind of a backlight, generally a LED backlight or a reflector, to make the picture visible to the viewer. There are two kinds of LCD units – passive matrix LCD that requires more power and the superior active matrix LCD unit, known to people as Thin Film Transistor (TFT) that draws less power.

The early LCD technology couldn’t maintain the colour for wide angle viewing, which led to the development of the In-Plane Switching (IPS) LCD panel. IPS panel arranges and switches the orientation of the liquid crystal molecules of standard LCD display between the glass substrates. This helps it to enhance viewing angles and improve colour reproduction as well. IPS LCD technology is responsible for accelerating the growth of the smartphone market and is the go-to display technology for prominent manufacturers.

The standard LCD display uses amorphous Silicon as the liquid for the display unit as it can be assembled into complex high-current driver circuits. This though restricts the display resolution and adds to overall device temperatures. Therefore, development of the technology led to replacing the amorphous Silicon with Polycrystalline Silicon, which boosted the screen resolution and maintains low temperatures. The larger and more uniform grains of polysilicon allow faster electron movement, resulting in higher resolution and higher refresh rates. It also was found to be cheaper to manufacture due to lower cost of certain key substrates. Therefore, the Low-Temperature PolySilicon (LTPS) LCD screen helps provide larger pixel densities, lower power consumption that standard LCD and controlled temperature ranges.

The AMOLED display technology is in a completely different league. It doesn’t bother with any liquid mechanism or complex grid structures. The panel uses an array of tiny LEDs placed on TFT modules. These LEDs have an organic construction that directly emits light and minimises its loss by eradicating certain filters. Since LEDs are physically different units, they can be asked to switch on and off as per the requirement of the display to form a picture. This is known as the Active Matrix system. Hence, an Active Matrix Organic Light Emitting Diode (AMOLED) display can produce deeper blacks by switching off individual LED pixels, resulting in high contrast pictures.

The honest answer is that it depends on the requirement of the user. If you want accurate colours from your display while wanting it to retain its vibrancy for a longer period of time, then any of the two LCD screens are the ideal choice. LTPS LCD display can provide higher picture resolution but deteriorates faster than standard IPS LCD display over time.

An AMOLED display will provide high contrast pictures any time but it too has the tendency to deteriorate faster than LCD panels. Therefore, if you are after greater picture quality, choose LTPS LCD or else settle for AMOLED for a vivid contrast picture experience.

If you want to buy a new monitor, you might wonder what kind of display technologies I should choose. In today’s market, there are two main types of computer monitors: TFT LCD monitors & IPS monitors.

The word TFT means Thin Film Transistor. It is the technology that is used in LCD displays.  We have additional resources if you would like to learn more about what is a TFT Display. This type of LCDs is also categorically referred to as an active-matrix LCD.

These LCDs can hold back some pixels while using other pixels so the LCD screen will be using a very minimum amount of energy to function (to modify the liquid crystal molecules between two electrodes). TFT LCDs have capacitors and transistors. These two elements play a key part in ensuring that the TFT display monitor functions by using a very small amount of energy while still generating vibrant, consistent images.

Industry nomenclature: TFT LCD panels or TFT screens can also be referred to as TN (Twisted Nematic) Type TFT displays or TN panels, or TN screen technology.

IPS (in-plane-switching) technology is like an improvement on the traditional TFT LCD display module in the sense that it has the same basic structure, but has more enhanced features and more widespread usability.

These LCD screens offer vibrant color, high contrast, and clear images at wide viewing angles. At a premium price. This technology is often used in high definition screens such as in gaming or entertainment.

Both TFT display and IPS display are active-matrix displays, neither can’t emit light on their own like OLED displays and have to be used with a back-light of white bright light to generate the picture. Newer panels utilize LED backlight (light-emitting diodes) to generate their light hence utilizing less power and requiring less depth by design. Neither TFT display nor IPS display can produce color, there is a layer of RGB (red, green, blue) color filter in each LCD pixels to produce the color consumers see. If you use a magnifier to inspect your monitor, you will see RGB color in each pixel. With an on/off switch and different level of brightness RGB, we can get many colors.

Wider viewing angles are not always welcome or needed. Image you work on the airplane. The person sitting next to you always looking at your screen, it can be very uncomfortable. There are more expensive technologies to narrow the viewing angle on purpose to protect the privacy.

Winner. IPS TFT screens have around 0.3 milliseconds response time while TN TFT screens responds around 10 milliseconds which makes the latter unsuitable for gaming

Winner. the images that IPS displays create are much more pristine and original than that of the TFT screen. IPS displays do this by making the pixels function in a parallel way. Because of such placing, the pixels can reflect light in a better way, and because of that, you get a better image within the display.

As the display screen made with IPS technology is mostly wide-set, it ensures that the aspect ratio of the screen would be wider. This ensures better visibility and a more realistic viewing experience with a stable effect.

Winner. While the TFT LCD has around 15% more power consumption vs IPS LCD, IPS has a lower transmittance which forces IPS displays to consume more power via backlights. TFT LCD helps battery life.

Normally, high-end products, such as Apple Mac computer monitors and Samsung mobile phones, generally use IPS panels. Some high-end TV and mobile phones even use AMOLED (Active Matrix Organic Light Emitting Diodes) displays. This cutting edge technology provides even better color reproduction, clear image quality, better color gamut, less power consumption when compared to LCD technology.

What you need to choose is AMOLED for your TV and mobile phones instead of PMOLED. If you have budget leftover, you can also add touch screen functionality as most of the touch nowadays uses PCAP (Projective Capacitive) touch panel.

This kind of touch technology was first introduced by Steve Jobs in the first-generation iPhone. Of course, a TFT LCD display can always meet the basic needs at the most efficient price. An IPS display can make your monitor standing out.

Over time, the purpose of using mobile phones or Smartphones has changed. Comparatively, it has now become a basic necessity of every individual. Smartphone has dramatically transformed the lives of individuals. It has now become a mini-computer that everyone carries in their pocket. Instead, you can have multiple things at your fingertips in a few seconds. While there are plenty of things to look for, AMOLED vs OLED is also a part of it.

Before purchasing any Smartphone, everyone goes through a list of specifications. This list includes display type, screen size, battery backup, supported operating system, total internal memory, and many others. Today, we have brought a comprehensive study of the significant display technologies available nowadays.

This article will introduce you to AMOLED vs OLED display technologies. Then, we will discuss the properties of both display technologies, followed by the difference between AMOLED vs OLED.

It stands for Natural Light-Emitting Diode, a type of LED technique that utilises LEDs wherein the light is of organic molecules that cause the LEDs to shine brighter. These organic LEDs are in use to make what are thought to be the best display panels in the world.

When you make an OLED display, you put organic films among two conductors to make them. As a result, a bright light comes out when electricity is used—a simple design with many advantages over other ways to show things.

OLEDs can be used to make emissive displays, which implies that each pixel can be controlled and emits its very own light. As a result, OLED displays have excellent picture quality. They have bright colours, fast motion, and most importantly, very high contrast. Most of all, “real” blacks are the most important.  The simple design of OLEDs also makes it easy to create flexible displays that can bend and move.

PMOLED stands for Passive Matrix Organic Light Emitting Diode. The PMOLEDs are easy to find and much cheaper than other LEDs, but they cannot work for a long duration as their lifespan is very short. Therefore, this type of display is generally for small devices up to 3 inches.

AMOLED stands for Active Matrix Organic Light Emitting Diode. This type of display is generally for large platforms. It contains TFT, which further consists of a storage capacitor. It also works on the same principle as OLED displays.

AMOLED offers no restriction on the size of the display. The power consumption of AMOLED is much less than other display technologies. The AMOLED provides incredible performance. It is thinner, lighter, and more flexible than any other display technology like LED, or LCD technology.

The AMOLED display is widely used in mobiles, laptops, and televisions as it offers excellent performance. Therefore, SAMSUNG has introduced AMOLED displays in almost every product. For example, Full HD Super AMOLED in Samsung Galaxy S4 and Samsung Galaxy Note 3, Super AMOLED in Samsung Galaxy S3, HD Super AMOLED in Samsung Galaxy Note, and HD Super AMOLED Plus in Samsung Galaxy S3. Apart from this, it is also used in AMOLED vs OLED creating the following:

So far, we have discussed OLED and AMOLED display technologies. Now, we will look at some of the differences between OLED and AMOLED display technology:

OLED comprises thin layers of the organic component, which emits light when the current passes through it. In this technology, each pixel transmits its own light. On the other side, AMOLED consists of an additional layer of thin-film transistors (TFTs). In AMOLED, the storage capacitors are used to maintain the pixel states.

While the technology is different among various manufacturers, Samsung’s edge AMOLED displays use plastic substrates with poly-Si TFT technology similar to how LG uses it in their POLED technology. This technology is what makes the possibility to build curved displays using an active-matrix OLED panel.

OLED display much deeper blacks as compared to the AMOLED displays. You cannot see the screen in AMOLED display under direct sunlight. The AMOLED display quality is much better than the OLEDs as it contains an additional layer of TFTs and follows backplane technologies.

The OLED devices are simple solid-state devices consisting of a thin layer of organic compounds in an emissive electroluminescent layer where the electricity generates.

These organic compounds are present between the protective layers of glass or plastic. Comparatively, AMOLED comprises an active matrix of OLED pixels along with an additional layer of TFTs. This extra layer is responsible for controlling the current flow in each pixel.

The OLED display offers a high level of control over pixels. Hence, it can be turned off completely, resulting in an excellent contrast ratio compared to the AMOLED displays and less power consumption. On the other side, AMOLED has faster refresh rates than OLEDs. Also, they offer a tremendous artificial contrast ratio as each pixel transmits light but consumes more power than OLEDs.

OLED displays are comparatively much thinner compared to the LCDs. Hence, it provides more efficient and bright presentations. In addition, OLED offers support for large display sizes compared to the traditional LCDs. AMOLEDs remove the limitation of display sizes. one can fit it into any display size.

Putting all the points mentioned above in view, the key difference to understand appropriately is that POLED is an OLED display with a plastic substrate. On the other hand, AMOLED is Samsung’s word for its display technology which is mainly for marketing. Therefore, most phone manufacturers having AMOLED displays mean that they are using Samsung displays. It is as simple as that. To add to that, all the curved display technology is made possible because of the usage of plastic substrate.

So, based on the points mentioned above, the difference between OLED and AMOLED displays, you can choose any of the two display technology at your convenience. Both are good, offer excellent performance, and are customised according to your requirements.

The AMOLED display has a higher quality than OLEDs since it has an additional layer of TTs and uses backplane technologies. When compared to OLED screens, AMOLED displays are far more flexible. As a result, they are substantially more expensive than an OLED display.

Window to the digital world, the display is one of the first seen features when selecting a smartphone, so a show must be good, and an AMOLED display offers the same. Offering a great viewing experience, here are the top 3 AMOLED screen smartphones available in the market right now:

Realme 8 Pro features a 6.4-inch Super AMOLED display with 411 PPI and a 2.5D curved display. It runs on Snapdragon 720G, bundled with Adreno 618 and 6GB of RAM. On the rear, the Realme 8 Pro has a quad-camera setup with 108-megapixels primary sensor, 8-megapixel ultra-wide angle sensor, 2-megapixel macro sensor, and a 2-megapixel monochrome sensor.

Coming to the front, it has a 16-megapixel selfie camera housed in the punch-hole display. It comes with a 4,500 mAh battery that supports Super Dart fast charging, with 100 per cent coming in just 47 min. The Realme 8 Pro is one of the best segments with a Super AMOLED FHD+ display. Media lovers will enjoy this phone with its deep blacks and vibrant colours.

The Xiaomi Mi 11 Lite runs on Snapdragon 732G chipset bundled with Adreno 618 GPU and up to 8GB RAM. The display front comes with a 6.55-inch AMOLED display with HDR 10+ support and 402 PPI.

The cameras have a triple rear camera setup with a 64-megapixel primary sensor, 8-megapixel ultra-wide angle sensor, and a 5-megapixel macro sensor. In addition, it has a 16-megapixel selfie camera housed in the punch-hole display on the front. It has a 4,250 mAh battery with 33W fast charging with USB Type-C. With the support for HDR 10+, the AMOLED display on the Mi 11 Lite is a treat for all media enthusiasts.

OPPO has recently launched the Oppo Reno 6 Pro with MediaTek’s Density 1200 chipset coupled with Mali-G77 MC9 GPU and up to 12GB of RAM. In addition, it comes with a 6.55-inch curved AMOLED FHD+ display with support for HDR 10+ and an Oleophobic coating.

On the rear, it comes with a quad-camera setup with a 64-megapixel primary sensor, an 8MP ultra-wide angle sensor, a 2-megapixel macro sensor, and a 2-megapixel depth sensor. In addition, it has a 32-megapixel selfie camera integrated inside the punch-hole on display on the front. It comes with a 4,500 mAh battery that supports 65W Super VOOC fast charging and can charge the phone 100 per cent in just 31 minutes. Since it comes with an FHD+ curved AMOLED display on the display front, it is a treat for gamers and media consumption lovers.

Smartphone displays have advanced significantly in recent years, more so than most people realise in this technological age. Display screens are similar to windows in the mobile world, which has seen a tremendous transformation in innovative products in the last several years. People have gotten more selective when buying a phone in recent years, and although all of the functions are important, the display is always the most noticeable.

Major smartphone manufacturers attempt to provide their consumers with the most delicate devices possible that incorporate the most up-to-date technologies. In AMOLED vs OLED, AMOLED is a type of OLED and a more prominent example of both OLED and POLED, so there’s no debate about which is superior.

Click here if you’re looking tosell phone online, or want torecycle old phones, and Cashify will help you get the process completed right at your doorstep.

Glass substrate with ITO electrodes. The shapes of these electrodes will determine the shapes that will appear when the LCD is switched ON. Vertical ridges etched on the surface are smooth.

A liquid-crystal display (LCD) is a flat-panel display or other electronically modulated optical device that uses the light-modulating properties of liquid crystals combined with polarizers. Liquid crystals do not emit light directlybacklight or reflector to produce images in color or monochrome.seven-segment displays, as in a digital clock, are all good examples of devices with these displays. They use the same basic technology, except that arbitrary images are made from a matrix of small pixels, while other displays have larger elements. LCDs can either be normally on (positive) or off (negative), depending on the polarizer arrangement. For example, a character positive LCD with a backlight will have black lettering on a background that is the color of the backlight, and a character negative LCD will have a black background with the letters being of the same color as the backlight. Optical filters are added to white on blue LCDs to give them their characteristic appearance.

LCDs are used in a wide range of applications, including LCD televisions, computer monitors, instrument panels, aircraft cockpit displays, and indoor and outdoor signage. Small LCD screens are common in LCD projectors and portable consumer devices such as digital cameras, watches, digital clocks, calculators, and mobile telephones, including smartphones. LCD screens are also used on consumer electronics products such as DVD players, video game devices and clocks. LCD screens have replaced heavy, bulky cathode-ray tube (CRT) displays in nearly all applications. LCD screens are available in a wider range of screen sizes than CRT and plasma displays, with LCD screens available in sizes ranging from tiny digital watches to very large television receivers. LCDs are slowly being replaced by OLEDs, which can be easily made into different shapes, and have a lower response time, wider color gamut, virtually infinite color contrast and viewing angles, lower weight for a given display size and a slimmer profile (because OLEDs use a single glass or plastic panel whereas LCDs use two glass panels; the thickness of the panels increases with size but the increase is more noticeable on LCDs) and potentially lower power consumption (as the display is only "on" where needed and there is no backlight). OLEDs, however, are more expensive for a given display size due to the very expensive electroluminescent materials or phosphors that they use. Also due to the use of phosphors, OLEDs suffer from screen burn-in and there is currently no way to recycle OLED displays, whereas LCD panels can be recycled, although the technology required to recycle LCDs is not yet widespread. Attempts to maintain the competitiveness of LCDs are quantum dot displays, marketed as SUHD, QLED or Triluminos, which are displays with blue LED backlighting and a Quantum-dot enhancement film (QDEF) that converts part of the blue light into red and green, offering similar performance to an OLED display at a lower price, but the quantum dot layer that gives these displays their characteristics can not yet be recycled.

Since LCD screens do not use phosphors, they rarely suffer image burn-in when a static image is displayed on a screen for a long time, e.g., the table frame for an airline flight schedule on an indoor sign. LCDs are, however, susceptible to image persistence.battery-powered electronic equipment more efficiently than a CRT can be. By 2008, annual sales of televisions with LCD screens exceeded sales of CRT units worldwide, and the CRT became obsolete for most purposes.

Each pixel of an LCD typically consists of a layer of molecules aligned between two transparent electrodes, often made of Indium-Tin oxide (ITO) and two polarizing filters (parallel and perpendicular polarizers), the axes of transmission of which are (in most of the cases) perpendicular to each other. Without the liquid crystal between the polarizing filters, light passing through the first filter would be blocked by the second (crossed) polarizer. Before an electric field is applied, the orientation of the liquid-crystal molecules is determined by the alignment at the surfaces of electrodes. In a twisted nematic (TN) device, the surface alignment directions at the two electrodes are perpendicular to each other, and so the molecules arrange themselves in a helical structure, or twist. This induces the rotation of the polarization of the incident light, and the device appears gray. If the applied voltage is large enough, the liquid crystal molecules in the center of the layer are almost completely untwisted and the polarization of the incident light is not rotated as it passes through the liquid crystal layer. This light will then be mainly polarized perpendicular to the second filter, and thus be blocked and the pixel will appear black. By controlling the voltage applied across the liquid crystal layer in each pixel, light can be allowed to pass through in varying amounts thus constituting different levels of gray.

The chemical formula of the liquid crystals used in LCDs may vary. Formulas may be patented.Sharp Corporation. The patent that covered that specific mixture expired.

Most color LCD systems use the same technique, with color filters used to generate red, green, and blue subpixels. The LCD color filters are made with a photolithography process on large glass sheets that are later glued with other glass sheets containing a TFT array, spacers and liquid crystal, creating several color LCDs that are then cut from one another and laminated with polarizer sheets. Red, green, blue and black photoresists (resists) are used. All resists contain a finely ground powdered pigment, with particles being just 40 nanometers across. The black resist is the first to be applied; this will create a black grid (known in the industry as a black matrix) that will separate red, green and blue subpixels from one another, increasing contrast ratios and preventing light from leaking from one subpixel onto other surrounding subpixels.Super-twisted nematic LCD, where the variable twist between tighter-spaced plates causes a varying double refraction birefringence, thus changing the hue.

LCD in a Texas Instruments calculator with top polarizer removed from device and placed on top, such that the top and bottom polarizers are perpendicular. As a result, the colors are inverted.

The optical effect of a TN device in the voltage-on state is far less dependent on variations in the device thickness than that in the voltage-off state. Because of this, TN displays with low information content and no backlighting are usually operated between crossed polarizers such that they appear bright with no voltage (the eye is much more sensitive to variations in the dark state than the bright state). As most of 2010-era LCDs are used in television sets, monitors and smartphones, they have high-resolution matrix arrays of pixels to display arbitrary images using backlighting with a dark background. When no image is displayed, different arrangements are used. For this purpose, TN LCDs are operated between parallel polarizers, whereas IPS LCDs feature crossed polarizers. In many applications IPS LCDs have replaced TN LCDs, particularly in smartphones. Both the liquid crystal material and the alignment layer material contain ionic compounds. If an electric field of one particular polarity is applied for a long period of time, this ionic material is attracted to the surfaces and degrades the device performance. This is avoided either by applying an alternating current or by reversing the polarity of the electric field as the device is addressed (the response of the liquid crystal layer is identical, regardless of the polarity of the applied field).

Displays for a small number of individual digits or fixed symbols (as in digital watches and pocket calculators) can be implemented with independent electrodes for each segment.alphanumeric or variable graphics displays are usually implemented with pixels arranged as a matrix consisting of electrically connected rows on one side of the LC layer and columns on the other side, which makes it possible to address each pixel at the intersections. The general method of matrix addressing consists of sequentially addressing one side of the matrix, for example by selecting the rows one-by-one and applying the picture information on the other side at the columns row-by-row. For details on the various matrix addressing schemes see passive-matrix and active-matrix addressed LCDs.

LCDs, along with OLED displays, are manufactured in cleanrooms borrowing techniques from semiconductor manufacturing and using large sheets of glass whose size has increased over time. Several displays are manufactured at the same time, and then cut from the sheet of glass, also known as the mother glass or LCD glass substrate. The increase in size allows more displays or larger displays to be made, just like with increasing wafer sizes in semiconductor manufacturing. The glass sizes are as follows:

Until Gen 8, manufacturers would not agree on a single mother glass size and as a result, different manufacturers would use slightly different glass sizes for the same generation. Some manufacturers have adopted Gen 8.6 mother glass sheets which are only slightly larger than Gen 8.5, allowing for more 50 and 58 inch LCDs to be made per mother glass, specially 58 inch LCDs, in which case 6 can be produced on a Gen 8.6 mother glass vs only 3 on a Gen 8.5 mother glass, significantly reducing waste.AGC Inc., Corning Inc., and Nippon Electric Glass.

The origins and the complex history of liquid-crystal displays from the perspective of an insider during the early days were described by Joseph A. Castellano in Liquid Gold: The Story of Liquid Crystal Displays and the Creation of an Industry.IEEE History Center.Peter J. Wild, can be found at the Engineering and Technology History Wiki.

In 1888,Friedrich Reinitzer (1858–1927) discovered the liquid crystalline nature of cholesterol extracted from carrots (that is, two melting points and generation of colors) and published his findings at a meeting of the Vienna Chemical Society on May 3, 1888 (F. Reinitzer: Beiträge zur Kenntniss des Cholesterins, Monatshefte für Chemie (Wien) 9, 421–441 (1888)).Otto Lehmann published his work "Flüssige Kristalle" (Liquid Crystals). In 1911, Charles Mauguin first experimented with liquid crystals confined between plates in thin layers.

In 1922, Georges Friedel described the structure and properties of liquid crystals and classified them in three types (nematics, smectics and cholesterics). In 1927, Vsevolod Frederiks devised the electrically switched light valve, called the Fréedericksz transition, the essential effect of all LCD technology. In 1936, the Marconi Wireless Telegraph company patented the first practical application of the technology, "The Liquid Crystal Light Valve". In 1962, the first major English language publication Molecular Structure and Properties of Liquid Crystals was published by Dr. George W. Gray.RCA found that liquid crystals had some interesting electro-optic characteristics and he realized an electro-optical effect by generating stripe-patterns in a thin layer of liquid crystal material by the application of a voltage. This effect is based on an electro-hydrodynamic instability forming what are now called "Williams domains" inside the liquid crystal.

The MOSFET (metal-oxide-semiconductor field-effect transistor) was invented by Mohamed M. Atalla and Dawon Kahng at Bell Labs in 1959, and presented in 1960.Paul K. Weimer at RCA developed the thin-film transistor (TFT) in 1962.

In 1964, George H. Heilmeier, then working at the RCA laboratories on the effect discovered by Williams achieved the switching of colors by field-induced realignment of dichroic dyes in a homeotropically oriented liquid crystal. Practical problems with this new electro-optical effect made Heilmeier continue to work on scattering effects in liquid crystals and finally the achievement of the first operational liquid-crystal display based on what he called the George H. Heilmeier was inducted in the National Inventors Hall of FameIEEE Milestone.

In the late 1960s, pioneering work on liquid crystals was undertaken by the UK"s Royal Radar Establishment at Malvern, England. The team at RRE supported ongoing work by George William Gray and his team at the University of Hull who ultimately discovered the cyanobiphenyl liquid crystals, which had correct stability and temperature properties for application in LCDs.

The idea of a TFT-based liquid-crystal display (LCD) was conceived by Bernard Lechner of RCA Laboratories in 1968.dynamic scattering mode (DSM) LCD that used standard discrete MOSFETs.

On December 4, 1970, the twisted nematic field effect (TN) in liquid crystals was filed for patent by Hoffmann-LaRoche in Switzerland, (Swiss patent No. 532 261) with Wolfgang Helfrich and Martin Schadt (then working for the Central Research Laboratories) listed as inventors.Brown, Boveri & Cie, its joint venture partner at that time, which produced TN displays for wristwatches and other applications during the 1970s for the international markets including the Japanese electronics industry, which soon produced the first digital quartz wristwatches with TN-LCDs and numerous other products. James Fergason, while working with Sardari Arora and Alfred Saupe at Kent State University Liquid Crystal Institute, filed an identical patent in the United States on April 22, 1971.ILIXCO (now LXD Incorporated), produced LCDs based on the TN-effect, which soon superseded the poor-quality DSM types due to improvements of lower operating voltages and lower power consumption. Tetsuro Hama and Izuhiko Nishimura of Seiko received a US patent dated February 1971, for an electronic wristwatch incorporating a TN-LCD.

In 1972, the concept of the active-matrix thin-film transistor (TFT) liquid-crystal display panel was prototyped in the United States by T. Peter Brody"s team at Westinghouse, in Pittsburgh, Pennsylvania.Westinghouse Research Laboratories demonstrated the first thin-film-transistor liquid-crystal display (TFT LCD).high-resolution and high-quality electronic visual display devices use TFT-based active matrix displays.active-matrix liquid-crystal display (AM LCD) in 1974, and then Brody coined the term "active matrix" in 1975.

In 1972 North American Rockwell Microelectronics Corp introduced the use of DSM LCDs for calculators for marketing by Lloyds Electronics Inc, though these required an internal light source for illumination.Sharp Corporation followed with DSM LCDs for pocket-sized calculators in 1973Seiko and its first 6-digit TN-LCD quartz wristwatch, and Casio"s "Casiotron". Color LCDs based on Guest-Host interaction were invented by a team at RCA in 1968.TFT LCDs similar to the prototypes developed by a Westinghouse team in 1972 were patented in 1976 by a team at Sharp consisting of Fumiaki Funada, Masataka Matsuura, and Tomio Wada,

In 1983, researchers at Brown, Boveri & Cie (BBC) Research Center, Switzerland, invented the passive matrix-addressed LCDs. H. Amstutz et al. were listed as inventors in the corresponding patent applications filed in Switzerland on July 7, 1983, and October 28, 1983. Patents were granted in Switzerland CH 665491, Europe EP 0131216,

The first color LCD televisions were developed as handheld televisions in Japan. In 1980, Hattori Seiko"s R&D group began development on color LCD pocket televisions.Seiko Epson released the first LCD television, the Epson TV Watch, a wristwatch equipped with a small active-matrix LCD television.dot matrix TN-LCD in 1983.Citizen Watch,TFT LCD.computer monitors and LCD televisions.3LCD projection technology in the 1980s, and licensed it for use in projectors in 1988.compact, full-color LCD projector.

In 1990, under different titles, inventors conceived electro optical effects as alternatives to twisted nematic field effect LCDs (TN- and STN- LCDs). One approach was to use interdigital electrodes on one glass substrate only to produce an electric field essentially parallel to the glass substrates.Germany by Guenter Baur et al. and patented in various countries.Hitachi work out various practical details of the IPS technology to interconnect the thin-film transistor array as a matrix and to avoid undesirable stray fields in between pixels.

Hitachi also improved the viewing angle dependence further by optimizing the shape of the electrodes (Super IPS). NEC and Hitachi become early manufacturers of active-matrix addressed LCDs based on the IPS technology. This is a milestone for implementing large-screen LCDs having acceptable visual performance for flat-panel computer monitors and television screens. In 1996, Samsung developed the optical patterning technique that enables multi-domain LCD. Multi-domain and In Plane Switching subsequently remain the dominant LCD designs through 2006.South Korea and Taiwan,

In 2007 the image quality of LCD televisions surpassed the image quality of cathode-ray-tube-based (CRT) TVs.LCD TVs were projected to account 50% of the 200 million TVs to be shipped globally in 2006, according to Displaybank.Toshiba announced 2560 × 1600 pixels on a 6.1-inch (155 mm) LCD panel, suitable for use in a tablet computer,transparent and flexible, but they cannot emit light without a backlight like OLED and microLED, which are other technologies that can also be made flexible and transparent.

In 2016, Panasonic developed IPS LCDs with a contrast ratio of 1,000,000:1, rivaling OLEDs. This technology was later put into mass production as dual layer, dual panel or LMCL (Light Modulating Cell Layer) LCDs. The technology uses 2 liquid crystal layers instead of one, and may be used along with a mini-LED backlight and quantum dot sheets.

Since LCDs produce no light of their own, they require external light to produce a visible image.backlight. Active-matrix LCDs are almost always backlit.Transflective LCDs combine the features of a backlit transmissive display and a reflective display.

CCFL: The LCD panel is lit either by two cold cathode fluorescent lamps placed at opposite edges of the display or an array of parallel CCFLs behind larger displays. A diffuser (made of PMMA acrylic plastic, also known as a wave or light guide/guiding plateinverter to convert whatever DC voltage the device uses (usually 5 or 12 V) to ≈1000 V needed to light a CCFL.

EL-WLED: The LCD panel is lit by a row of white LEDs placed at one or more edges of the screen. A light diffuser (light guide plate, LGP) is then used to spread the light evenly across the whole display, similarly to edge-lit CCFL LCD backlights. The diffuser is made out of either PMMA plastic or special glass, PMMA is used in most cases because it is rugged, while special glass is used when the thickness of the LCD is of primary concern, because it doesn"t expand as much when heated or exposed to moisture, which allows LCDs to be just 5mm thick. Quantum dots may be placed on top of the diffuser as a quantum dot enhancement film (QDEF, in which case they need a layer to be protected from heat and humidity) or on the color filter of the LCD, replacing the resists that are normally used.

WLED array: The LCD panel is lit by a full array of white LEDs placed behind a diffuser behind the panel. LCDs that use this implementation will usually have the ability to dim or completely turn off the LEDs in the dark areas of the image being displayed, effectively increasing the contrast ratio of the display. The precision with which this can be done will depend on the number of dimming zones of the display. The more dimming zones, the more precise the dimming, with less obvious blooming artifacts which are visible as dark grey patches surrounded by the unlit areas of the LCD. As of 2012, this design gets most of its use from upscale, larger-screen LCD televisions.

RGB-LED array: Similar to the WLED array, except the panel is lit by a full array of RGB LEDs. While displays lit with white LEDs usually have a poorer color gamut than CCFL lit displays, panels lit with RGB LEDs have very wide color gamuts. This implementation is most popular on professional graphics editing LCDs. As of 2012, LCDs in this category usually cost more than $1000. As of 2016 the cost of this category has drastically reduced and such LCD televisions obtained same price levels as the former 28" (71 cm) CRT based categories.

Monochrome LEDs: such as red, green, yellow or blue LEDs are used in the small passive monochrome LCDs typically used in clocks, watches and small appliances.

Mini-LED: Backlighting with Mini-LEDs can support over a thousand of Full-area Local Area Dimming (FLAD) zones. This allows deeper blacks and higher contrast ratio.MicroLED.)

Today, most LCD screens are being designed with an LED backlight instead of the traditional CCFL backlight, while that backlight is dynamically controlled with the video information (dynamic backlight control). The combination with the dynamic backlight control, invented by Philips researchers Douglas Stanton, Martinus Stroomer and Adrianus de Vaan, simultaneously increases the dynamic range of the display system (also marketed as HDR, high dynamic range television or FLAD, full-area local area dimming).

The LCD backlight systems are made highly efficient by applying optical films such as prismatic structure (prism sheet) to gain the light into th
