Probably our testsample, the current Toshiba Satellite P100-102 is one of the laptops with the highest performance. Equipped with a Core Duo processor and a NVIDIA Geforce 7600 the Satellite P100-102 is in the best way to be ready for the future.
The design of the case is dominated by the typical Toshiba alignment. Particularly accentuated are the Harman/Kardon boxes at the front edge of the Satellite, which are impressively lit up by means of LED.
The laptop is coloured in silver and black. The display cover in orange/brass colour is a question of taste. I personally I think it"s ok. The case is manufactured exclusively in plastic, which however throughout leaves a high-quality impression.
The double hook closure system works precisely and closes the display properly matching and can be handled user-friendly by a slidegate with a rough surface. The hinges permit a wobbling of the display. That"s a negative aspect.
At first sight the display seems to be sufficiently bright, and also the color representation makes a good impression. Unfortunately also an easy overthrow distortion of the display and with exact view recognizable illuminating weaknesses can be recognized.
During the brightness measuring of the reflecting 17 inch WXGA TruBrite TFT display we determined an illuminating of 62%, which is below average and a moderate maximum brightness of 137.4 cd/m².
In principle, the display can be described as very stable respecting the point of viewing angle. Within the horizontal range the legibility is only limited by the arising reflections and particularly with a high angle change. Within the vertical range slight color changes occur, but the full legibility remains.
LoudspeakerLike its Toshiba companions of the multimedia segment the Satellite P100 is equipped with Harman/Kardon loudspeakers, which offer quite good sound. They cannot keep up with those of the Qosmio F20 (particularly within the low-frequency range), but they are very good compared with conventional speakers.
LCD Controllers & Drivers└ LEDs, LCDs & Display Modules└ Electronic Components & Semiconductors└ Electrical Equipment & Supplies└ Business & IndustrialAll CategoriesAntiquesArtBabyBooks & MagazinesBusiness & IndustrialCameras & PhotoCell Phones & AccessoriesClothing, Shoes & AccessoriesCoins & Paper MoneyCollectiblesComputers/Tablets & NetworkingConsumer ElectronicsCraftsDolls & BearsMovies & TVEntertainment MemorabiliaGift Cards & CouponsHealth & BeautyHome & GardenJewelry & WatchesMusicMusical Instruments & GearPet SuppliesPottery & GlassReal EstateSpecialty ServicesSporting GoodsSports Mem, Cards & Fan ShopStampsTickets & ExperiencesToys & HobbiesTravelVideo Games & ConsolesEverything Else
The Toshiba Satellite C660 features a sophisticated black textured finish. With its subtle yet elegant design the Satellite C660 looks the part at home, school, university, in the office, and out and about. Packed full with smart design and technology such as Toshiba"s multi-touch touchpad, facial recognition software, media controller, and LifeSpace suite, the Satellite C660 is an ideal laptop for work and play.
Maximise your experience of Windows 7 and see the Satellite C660 come alive with LifeSpace. A free productivity application suite, LifeSpace gives you a personalised approach to accessing your files, organising daily activities, projects and more. LifeSpace is a unique collection of apps designed by Toshiba to make computing simple, intuitive and fun and is great for work and home across all age groups. Complimenting the Windows 7 operating system, LifeSpace helps you simplify your PC experience through personalisation and quicker access to the things that matter the most to you, thanks to Bulletin Board and ReelTime.
Remember that file you looked at a while back but have no idea where you kept it on your PC? Well with Toshiba’s ReelTime, a visual timeline of your file history up to 3 months old is kept so that you can cut through the clutter to find what you are looking for quickly and easily. It sits above the Windows taskbar and the timeline can be easily scrolled through until you find the file you"re looking for.
The Satellite C660 features an integrated web camera with Toshiba Face Recognition. The camera and microphone let you see and hear your contacts online, and can take still pictures, video clips and audio notes. With Toshiba"s integrated WebCam communication is made easy--network with friends and family from the comfort of your own home.
Using numerous passwords can complicate things so instead of worrying about remembering all of these or using a single password that can be compromised the Satellite C660 features Toshiba Face Recognition--the fun and easy way to log on to your laptop. Toshiba Face Recognition is a biometric-based identification method and uses the WebCam to automatically detect 14 separate facial feature points to verify your identity and grant you fast and simple access to your data. Once your facial profile has been saved it can be used to access the system with no need to enter additional passwords. Additional users can store their own unique facial recognition profile, allowing your whole family to use the computer securely, and with peace of mind.
A new interface to make content streaming easy, Toshiba Media Controller software facilitates media sharing between connected multimedia devices. Media Controller allows you to stream videos, music and pictures from a media library to TVs, laptops, smartphones or media players through a simple drag-and-drop interface. The system allows media sharing on networks under one single unified user interface through Windows 7"s "play to" functionality and DLNA (Digital Living Network Alliance) which ensures interoperability of connected devices in a home multimedia network. Toshiba Media Controller makes multimedia file sharing a breeze. Easily display videos captured with a mobile phone via a network connection directly on a laptop and stream movies stored on a laptop to a large HD TV (requires DLNA-certified device) without knowledge about network configuration and with only a few clicks.
Connect to the Internet easily thanks to Toshiba"s ConfigFree suite. ConfigFree features Wireless Radar which displays nearby active Wi-Fi access points in a radar-like graphical interface. Draw a line from your computer to easily connect to Wi-Fi access points. Connectivity Doctor analyses your network connection and assists in fixing problems, features easy diagnosis and repair of communication problems, and shows detailed network. Profile Settings allows you to easily switch between network configurations and profiles can be created to capture the settings in different locations and switched automatically or semi-automatically. Finally, Wi-Fi Protected Setup (WPS) features a push button config setting to easily setup a secured connection between an access point/router and your laptop.
Shop the Toshiba Satellite C600 SeriesToshiba Satellite C660-17LToshiba Satellite C660-21QToshiba Satellite C660-220Toshiba Satellite C660-23MToshiba Satellite C670-14NToshiba Satellite C670D-110Screen Size33.8cm (13.3") 39.6cm (15.6”) 39.6cm (15.6”) 39.6cm (15.6”) 43.9cm (17.3”) 43.9cm (17.3”)Screen Resolution1,366 x 768 1,366 x 768 1,366 x 768 1,366 x 768 1,600 x 900 1,600 x 900ProcessorIntel Pentium P6100 Intel Pentium P6100 Intel Core i3-370M Intel Core i3-370M Intel Pentium B940 AMD Dual-Core E-350Memory3 GB 6 GB 4 GB 6 GB 4 GB 4 GBStorage500 GB 500 GB 500 GB 640 GB 500 GB 500 GBGraphicsIntel Graphics Media Accelerator HD Intel Graphics Media Accelerator HD Intel Graphics Media Accelerator HD Intel Graphics Media Accelerator HD Intel HD Graphics 3000 AMD Radeon HD 6310 GraphicsOptical DriveDVD Super Multi DVD Super Multi DVD Super Multi DVD Super Multi DVD Super Multi DVD Super Multi
Checking a TFT lcd driver is very messy thing especially if its a Chinese manufactured TFT. TFT’s that are supplied by Chinese manufactures are cheap and every body loves to purchase them since they are cheap,but people are unaware of the problems that comes in future when finding the datasheet or specs of the particular TFT they purchased. Chinese manufactures did not supply datasheet of TFT or its driver. The only thing they do is writes about the TFT driver their lcd’s are using on their websites. I also get in trouble when i started with TFT’s because i also purchased a cheap one from aliexpress.com. After so many trials i succeeded in identifying the driver and initializing it. Now i though to write a routine that can identify the driver.
I wrote a simple Arduino Sketch that can easily and correctly identify the TFT Lcd driver. I checked it on 2.4, 3.2 and 3.8 inch 8-bit TFT lcd and it is identifying the drivers correctly. The drivers which i successfully recognized are ILI9325, ILI9328, ILI9341, ILI9335, ST7783, ST7781 and ST7787. It can also recognize other drivers such as ML9863A, ML9480 and ML9445 but i don’t have tft’s that are using this drivers.
The basic idea behind reading the driver is reading the device ID. Since all the drivers have their ID’s present in their register no 0x00, so what i do is read this register and identify which driver tft is using. Reading the register is also a complex task, but i have gone through it many times and i am well aware of how to read register. A simple timing diagram from ST7781 driver explains all. I am using tft in 8-bit interface so i uploaded timing diagram of 8-bit parallel interface. The diagram below is taken from datasheet of ST7781 tft lcd driver.
The most complex tft i came across is from a Chinese manufacturer “mcufriend”. mcufriend website says that they use ILI9341 and ILI9325 drivers for their tft’s. But what i found is strange their tft’s are using ST7781 driver(Device ID=7783). This is really a mesh. I have their 2.4 inch tft which according to their website is using ILI9341 driver but i found ST7783 driver(Device ID=7783). The tft i have is shown below.
I am using Arduino uno to read driver. I inserted my lcd on arduino uno and read the driver. After reading driver i am printing its number on Serial Monitor.
Note:On serial monitor driver number will be displayed like if your lcd is using ST7783 controller than on serial monitor 7783 will be displayed or if tft is using ILI9341 than on 9341 will be displayed.
The code works on Arduino uno perfectly but if you are using any other board, than just change the pin numbers according to the board that you are using also check out for the Ports D and B. TFT Data Pin D0 is connected to Port-B Pin#0 and D1 is connected to Port-B Pin#1. TFT Data Pins D2 to D7 are connected to Port-D Pins 2,3,4,5,6,7. So if you are using Arduino mega than check for the Ports D and B and Make connections according to them. Arduino mega is working on ATmega2560 or ATmega1280 Microcontroller and Arduino uno is working on ATmega328p Microcontroller so both platforms have ports on different locations on arduino board so first check them and then make connections. The same process applies to all Arduino boards.
